| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | GB3733.2-83 | Adapter G22 | 5 | ||
| 2 | JB1002-77 | Seal washer 27 | 5 | ||
| 3 | LG30F.02III.02.01 | Transmission valve oil-inlet pipe | 1 | ||
| 4 | LG30F.02III.02.02 | Transmission valve oil-outlet pipe | 1 | ||
| 5 | H-H/22/22-II-L600 | Control valve oil-inlet/outlet hose | 2 | ||
| 6 | LG30F.02III.02.03 | Oil filter oil-outlet pipe | 1 | ||
| 7 | LG30F.02III.02.04 | Torque converter oil-inlet pipe | 1 | ||
| 8 | LG30F.02III.02.05 | Lubricating tube from cooler to transmission | 1 | ||
| 9 | LG30F.02III.02-001 | Transmission oil-return adapter | 1 | ||
| 10 | GB3733.2-83 | Adapter G28 | 2 | ||
| 11 | JB1002-77 | Seal washer 33 | 2 | ||
| 12 | H-H/25/28-II-L800 | Torque converter oil-return hose | 1 | ||
| 13 | H-H/25/28-II-L950 | Transmission pump oil-suction hose | 1 | ||
| 14 | LG30F.02III.02.06 | Transmission pump oil-suction pipe | 1 | ||
| 15 | LG30F.02III.02-002 | Torque converter oil-return adapter | 1 | ||
| 16 | LG30F.02III.02.07 | Torque converter oil-outlet pipe | 1 | ||
| 17 | LG30F.02III.02-003 | Pipe clip | 4 | ||
| 18 | GB/T5783 | Bolt M8x15 | 8 | ||
| 19 | GB/T93 | Washer 8 | 8 | ||
| 20 | H-H/22/22-II-L1300 | Cooler oil-inlet/outlet hose | 2 | ||
| 21 | GB/T5783 | Bolt M10x30 | 6 | ||
| 22 | GB/T93 | Washer 10 | 6 | ||
| 23 | LG30F.02.02.01 |
в наличии
Single-stage gear pump
|
|
1 | |
| 24 | 90B-B/22/22-II-L600 | Hose from transmission pump to oil filter | 1 | ||
| 25 | LG30F.02I.02-009 | Filter oil-return connector | 1 | ||
| 26 | JB1002-77 | Seal washer 22 | 1 | ||
| 27 | LG853.02.02.01 | Oil filter | 1 | ||
| 28 | GB/T5782 | Bolt M8x45 | 4 | ||
| 29 | GB/T6170 | Nut M8 | 4 | ||
| 30 | GB/T97.1 | Washer M8 | 8 | ||
| 31 | LG30F.02I.02-002 | Filter oil-inlet connector | 1 | ||
| 32 | JB/T1002 | Seal washer 30 | 1 | ||
| 33 | ф19x2x110 | Oil-return hose | 1 | ||
| 34 | JB/T8870-1999 | Pipe clip(ф22-32) | 4 | ||
| 35 | GB5628.2-85 | Adapter A5 | 1 | ||
| 36 | JB1002 | Seal washer 10 | 1 | ||
| 37 | LG853.15.35 | Transmission valve pressure gauge tube | 1 | ||
| 38 | ф19x2x250 | Oil-return hose | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL30E.5G-1 |
под заказ
Transmission case
|
|
1 | |
| 2 | GB/T119-2000 | Cylindrical pin | 2 | ||
| 3 | ZL30E.5-2A |
в наличии
Transmission cover
|
|
1 | |
| 4 | ZL30E.5-3 | Seal gasket | 1 | ||
| 5 | ZL30E.5.1 | Shaft I clutch assembly | 1 | ||
| 6 | ZL30E.5.3 | Shaft II clutch assembly | 1 | ||
| 7 | ZL30E.5.4 |
в наличии
Shaft III clutch assembly
|
|
1 | |
| 8 | ZL30E.5-4 |
в наличии
Reverse gear
|
|
1 | |
| 9 | GB893.1-86 |
под заказ
Spacer 90
|
3 | ||
| 10 | GB/T276-94 |
под заказ
Bearing 6308
|
1 | ||
| 11 | ZL30E.5-7 |
в наличии
Shaft sleeve
|
|
1 | |
| 12 | GB894.1-86 |
под заказ
Spacer 40
|
1 | ||
| 13 | ZL30E.5-5 |
под заказ
Shaft sleeve
|
|
1 | |
| 14 | ZL30E.5-6 |
в наличии
Reverse gear shaft
|
|
1 | |
| 15 | GB3452.1-82 |
под заказ
O-ring 45x2.65
|
1 | ||
| 16 | ZL30E.5-26A | Seal gasket | 1 | ||
| 17 | GB93.1-87 | Washer 10 | 47 | ||
| 18 | GB/T5782-2000 |
под заказ
Bolt M10x30
|
15 | ||
| 19 | ZL30E.5.2 |
под заказ
Shaft I end cover assembly
|
|
1 | |
| 20 | ZL30E.5-8 |
в наличии
Seal gasket
|
|
2 | |
| 21 | GB93.1-87 | Washer 12 | 35 | ||
| 22 | GB5782-2000 | Bolt M12x35 | 29 | ||
| 23 | ZL30E.5.9A |
в наличии
Shaft II end cover assembly
|
|
1 | |
| 24 | ZL30E.5.5A |
в наличии
Shaft III end cover assembly
|
|
1 | |
| 25 | ZL30E.5-10 | Seal gasket | 1 | ||
| 26 | ZL1615.2A | Brake | 1 | ||
| 27 | ZL30E.5-16 |
в наличии
Front bearing cover
|
|
1 | |
| 28 | ZL30E.5-13 |
в наличии
Adjusting washer
|
|
1 | |
| 29 | GB/T276-94 |
под заказ
Bearing 6312
|
2 | ||
| 30 | ZL30E.5-12 |
под заказ
Shaft sleeve
|
|
1 | |
| 31 | ZL30E.5-11 |
под заказ
Press plate
|
2 | ||
| 32 | ZL30E.5-31 |
под заказ
Gasket
|
|
1 | |
| 33 | JB980-80 | Nylon lock nut M33x1.5 | 2 | ||
| 34 | GB3452.1-82 |
под заказ
O-ring 42.5x5.3
|
1 | ||
| 35 | HG4-339-66 |
под заказ
Frame oil seal 65x90x12
|
2 | ||
| 36 | ZL30E.5B.17 |
в наличии
Front output flange assembly
|
|
1 | |
| 37 | ZL30E.5-15 |
в наличии
Seal gasket
|
|
2 | |
| 38 | ZL30E.5-19 |
под заказ
Shaft sleeve
|
1 | ||
| 39 | ZL30E.5-14A |
в наличии
Output driven gear
|
|
1 | |
| 40 | GB/T5782-2000 |
под заказ
Bolt M10x35
|
28 | ||
| 41 | GB/T 825-1988 | Eye screw M16x28 | 1 | ||
| 42 | ZL30E.5.20 |
под заказ
Vent assembly
|
1 | ||
| 43 | GB/T5782-2000 |
под заказ
Bolt M12x100
|
6 | ||
| 44 | ZL30E.5.8 |
в наличии
Control valve
|
|
1 | |
| 45 | ZL30E.5.11A | Forward gear oil pipe | 1 | ||
| 46 | ZL30E.5-33 |
в наличии
Adapter
|
|
10 | |
| 47 | JB982-77 |
под заказ
Combined washer 10
|
10 | ||
| 48 | ZL30E.5.12A | Reverse gear oil pipe | 1 | ||
| 49 | ZL30E.5.14A |
в наличии
Gear II oil pipe
|
|
1 | |
| 50 | ZL30E.5.15A |
под заказ
Gear I oil pipe
|
1 | ||
| 51 | ZL30E.5.16A | Reverse gear lubrication oil tube | 1 | ||
| 52 | GB5626.2-85 | Adapter A8 | 2 | ||
| 53 | ZL30E.5G.21 | Oil-return control valve | 1 | ||
| 54 | ZL30E.5-18 |
в наличии
Connector
|
|
1 | |
| 55 | GB/T5782-2000 |
под заказ
Bolt M16x40
|
8 | ||
| 56 | GB/T93-1987 | Washer 16 | 8 | ||
| 57 | ZL30E.5.18A | Shaft I lubrication oil pipe | 1 | ||
| 58 | GB5629.2-85 | Adapter A10 | 3 | ||
| 59 | ZL30E.5.19A | Shaft III lubrication oil pipe | 1 | ||
| 60 | ZL30E.5.6 |
в наличии
Bracket
|
|
1 | |
| 61 | ZL30E.5.13 |
в наличии
Oil-filling assembly
|
|
1 | |
| 62 | ZL30E.5-22 | Brake bracket | 1 | ||
| 63 | ZL30E.5-21 | Vertical brake bracket | 1 | ||
| 64 | ZL30E.5-32 |
в наличии
Seal gasket
|
|
3 | |
| 65 | ZL30E.5-29 | Adjusting washer | 3 | ||
| 66 | HG4-339-66 |
под заказ
Frame oil seal 55x80x12
|
1 | ||
| 67 | ZL30E.5-25 | Washer | 1 | ||
| 68 | ZL30E.5-30 | Seal gasket | 1 | ||
| 69 | JB980-80 | Nylon lock nut M24x1.5 | 1 | ||
| 70 | ZL30E.5-27 |
в наличии
Input flange
|
|
1 | |
| 71 | ZL30E.5-28 | Oil seal cover | 1 | ||
| 72 | ZL30E.5-17A | End cover | 2 | ||
| 73 | ZL30E.5-23 | Rear bearing end cover | 1 | ||
| 74 | HG4-339-66 |
под заказ
Frame oil seal 60x85x12
|
2 | ||
| 75 | ZL30E.5-24 |
в наличии
Rear output flange
|
|
1 | |
| 76 | ZL30E.5-20A | Output shaft | 1 | ||
| 77 | ZL30E.5.7(ZL30E.5B1.2) | Filter assembly | 1 | ||
| 78 | GB/T5782-2000 |
под заказ
Bolt M10x40
|
4 | ||
| 81 | ZL30E.5.1-9 |
под заказ
Plug
|
1 | ||
| 82 | ZL30E.5.22A | Gear III oil pipe | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | LG380F.03.01 |
в наличии
Transmission assembly
|
|
1 | |
| 2 | GB/T97.1 | Washer 16 | 8 | ||
| 3 | GB/T890 | Nut M16 | 4 | ||
| 4 | GB/T5783 | Bolt M16x50 | 4 | ||
| 5 | LG380F.03.02 |
в наличии
Brake
|
|
1 |
