| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 54C0199 | CHAIN | 1 | ||
| 2 | 07B0003 | SNAP RING | 1 | ||
| 3 | 16C0044 | BREATHER CAP AS (S.C: Z) | 1 | ||
| 4 | 12D0273 | STRAINER (S.C: Z) | 1 | ||
| 5 | 20A0002 | DIPSTICK | 1 | ||
| 6 | 04D1056 | HOUSING | 1 | ||
| 7 | 81A0197 | RUBBER WASHER | 1 | ||
| 8 | 06B0024 | WASHER | 6 | ||
| 9 | 06B0003 | WASHER | 6 | ||
| 10 | 00B0022 | BOLT | 6 |
800-950 руб. |
|
| 11 | 20A6796 | PROTECTIVE COVER | 1 | ||
| 12 | 10D3685 | CONNECTING SUPPORT | 1 | ||
| 13 | 04B0002 | SCREW | 2 | ||
| 14 | 06B0117 | WASHER | 4 | ||
| 15 | 06B0015 | WASHER | 6 | ||
| 16 | 06B0012 | WASHER | 6 | ||
| 17 | 00B0014 | BOLT | 6 | ||
| 18 | 03B0024 | PLUG | 1 | ||
| 19 | 12B0381 | O-RING | 1 | ||
| 20 | 12B0238 | O-RING | 1 | ||
| 21 | 53A0140 | FLANGE COVER | 1 | ||
| 22 | 12B0239 | O-RING | 1 | ||
| 23 | 50D0060 | PLUG | 1 | ||
| 24 | 00B0012 | BOLT | 6 | ||
| 25 | 06B0002 | WASHER | 6 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 37C0700 | BAFFLE | 1 | ||
| 2 | 06B0001 | WASHER | 16 | ||
| 3 | 06B0002 | WASHER | 16 | ||
| 4 | 00B0012 | BOLT | 16 | ||
| 5 | 03B0053 | NUT | 4 | ||
| 6 | 37C0702 | BAFFLE | 1 | ||
| 7 | 37C0701 | BAFFLE | 1 | ||
| 8 | 09C0244 | CLAMP | 2 | ||
| 9 | 32A0891 | HOSE (S/N -223925) | 1 | ||
| 10 | 45D0852 | SHROUD (S/N -223925) | 1 | ||
| 11 | 06B0086 | WASHER | 8 | ||
| 12 | 06B0006 | WASHER | 8 | ||
| 13 | 00B0085 | BOLT | 8 | ||
| 14 | 03B0021 | NUT | 8 | ||
| 15 | 45D0720 | PROTECTION SHIELD | 2 | ||
| 16 | 09C0234 | CLAMP | 2 | ||
| 17 | 32A0466 | TUBE | 1 | ||
| 18 | 06B0008 | WASHER |
|
8 |
20-30 руб. |
| 19 | 00B0017 | BOLT |
|
8 |
80-90 руб. |
| 20 | 23A8306 | PLATE | 1 | ||
| 21 | 10A0687 | SHIM | 2 | ||
| 22 | 20C0052 | OIL COOLER | 1 | ||
| 23 | 20C0044 | WATER RADIATOR |
|
1 |
62000-72000 руб. |
| 24 | 20C0051 | OIL COOLER | 1 | ||
| 25 | 06B0012 | WASHER | 4 | ||
| 26 | 06B0015 | WASHER | 4 | ||
| 27 | 00B0095 | BOLT | 4 | ||
| 28 | 23A8307 | PLATE | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 12D0010 | INPUT FLANGE | 1 | ||
| 2 | 34C0608 | LOCKNUT | 1 | ||
| 4 | 13B0169 | OIL SEAL | 1 | ||
| 5 | 53A0307 | CAP | 1 | ||
| 6 | 00B0275 | BOLT | 8 | ||
| 7 | 06B0013 | WASHER | 8 | ||
| 8 | 80A0021 | SHIM | 1 | ||
| 9 | 57A0024 | SHIM | 1 | ||
| 10 | 43A0085 | SPIRAL BEVEL GEAR S/N -196519 | 1 | ||
| 11 | 55A0077 | BEARING BUSHING | 1 | ||
| 12 | 23B0019 | TAP.ROLLER BRG 31312 |
|
1 |
2300-2700 руб. |
| 13 | 44C0019 | LOCK BOLT | 1 | ||
| 14 | 03B0154 | NUT | 1 | ||
| 15 | 76A0011 | LOCKING PLATE | 1 | ||
| 16 | 22B0002 | ROLLER BEARING 92508E | 1 | ||
| 17 | 07B0038 | SNAP RING | 1 | ||
| 18 | 34C0002 | CARRIER AS | 1 | ||
| 19 | 56A0089 | WEAR WASHER | 4 | ||
| 20 | 43A0002 | BEVEL GEAR | 4 | ||
| 21 | 03B0062 | ADJUSTING NUT | 2 | ||
| 22 | 71A0016 | DIFF HOUSING | 1 | ||
| 23 | 63A0005 | SPIDER | 1 | ||
| 24 | 43A0011 | HALF SHAFT GEAR | 2 | ||
| 25 | 56A0042 | WEAR WASHER | 2 | ||
| 26 | 02B0015 | BOLT | 4 | ||
| 27 | 06B0270 | HARD WASHER | 4 | ||
| 28 | 40B0006 | STEEL WIRE | 2 | ||
| 29 | 21A0040 | FASTENER | 2 | ||
| 30 | 02B0012 | BOLT | 2 | ||
| 31 | 06B0002 | WASHER | 2 | ||
| 32 | 01B0616 | BOLT | 8 | ||
| 33 | 43A0148 | SPIRAL BEVEL GEAR | 1 | ||
| 34 | 01B0546 | BOLT | 12 | ||
| 35 | 03V0537 | NUT | 20 | ||
| 36 | 06B0214 | HARD WASHER | 20 | ||
| 37 | 23B0012 | TAP.ROLLER BRG 32216 | 1 | ||
| 38 | 41C0264 | BUSHING | 1 | ||
| 40 | 23B0018 | TAP.ROLLER BRG 31311 | 1 | ||
| 41 | 12B0105 | O-RING | 1 | ||
| 43 | 71A0831 | DIFF HOUSING | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 00 | SP103881 | TOOL KIT | 1 | ||
| 1 | 05C0007 | OIL PIPE AS | 1 | ||
| 2 | 00A0040 | CONNECTOR | 2 | ||
| 3 | 56A0045 | WASHER | 4 | ||
| 4 | 00A0041 | DEFLATING VALVE SEAT | 2 | ||
| 5 | 00A0044 | DEFLATING VALVE | 2 | ||
| 6 | 71A0018 | CLAMP | 1 | ||
| 7 | 12B0481 | O-RING |
|
4 |
20-30 руб. |
| 8 | 35C0025 | FRICTION LINING AS |
|
2 |
550-650 руб. |
| 9 | 50A0009 | PISTON |
|
4 |
600-700 руб. |
| 10 | 13B0108 | SEAL | 4 | ||
| 11 | 13B0008 | DUST RING |
|
4 |
900-1000 руб. |
| 12 | 00B0019 | BOLT | 16 | ||
| 13 | 06B0002 | WASHER | 16 | ||
| 14 | 00A1965 | CONNECTOR | 1 | ||
| 15 | 12B0245 | O-RING | 2 | ||
| 16 | 00A0356 | BOLT | 1 | ||
| 17 | 53A0042 | CYLINDER HEAD | 1 | ||
| 18 | 01B0043 | BOLT |
|
7 | |
| 19 | 06B0014 | WASHER | 7 | ||
| 20 | 04B0027 | LOCK SCREW | 4 | ||
| 21 | 03B0053 | NUT | 4 | ||
| 22 | 61A0045 | PIN | 4 | ||
| 23 | 53A0043 | CYLINDER HEAD |
|
3 |
180-210 руб. |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 12D0032 | INPUT FLANGE | 1 | ||
| 2 | 34C0608 | LOCKNUT | 1 | ||
| 4 | 13B0169 | OIL SEAL | 1 | ||
| 5 | 53A0307 | CAP | 1 | ||
| 6 | 00B0275 | BOLT | 8 | ||
| 7 | 06B0013 | WASHER | 8 | ||
| 8 | 80A0021 | SHIM | 1 | ||
| 9 | 57A0024 | SHIM | 1 | ||
| 10 | 43A0001 | PINION S/N -196519 | 1 | ||
| 11 | 55A0077 | BEARING BUSHING | 1 | ||
| 12 | 23B0019 | TAP.ROLLER BRG 31312 |
|
1 |
2300-2700 руб. |
| 13 | 44C0019 | LOCK BOLT | 1 | ||
| 14 | 03B0154 | NUT | 1 | ||
| 15 | 76A0011 | LOCKING PLATE | 1 | ||
| 16 | 22B0003 | ROLLER BEARING | 1 | ||
| 17 | 07B0038 | SNAP RING | 1 | ||
| 18 | 34C0002 | CARRIER AS | 1 | ||
| 19 | 56A0089 | WEAR WASHER | 4 | ||
| 20 | 43A0002 | BEVEL GEAR | 4 | ||
| 21 | 03B0062 | ADJUSTING NUT | 2 | ||
| 22 | 71A0016 | DIFF HOUSING | 1 | ||
| 23 | 63A0005 | SPIDER | 1 | ||
| 24 | 43A0011 | HALF SHAFT GEAR | 2 | ||
| 25 | 56A0042 | WEAR WASHER | 2 | ||
| 26 | 02B0015 | BOLT | 4 | ||
| 27 | 06B0270 | HARD WASHER | 4 | ||
| 28 | 40B0006 | STEEL WIRE | 2 | ||
| 29 | 21A0040 | FASTENER | 2 | ||
| 30 | 02B0012 | BOLT | 2 | ||
| 31 | 06B0002 | WASHER | 2 | ||
| 32 | 01B0616 | BOLT | 8 | ||
| 33 | 43A0149 | SPIRAL BEVEL GEAR | 1 | ||
| 34 | 01B0546 | BOLT | 12 | ||
| 35 | 03V0537 | NUT | 20 | ||
| 36 | 06B0214 | HARD WASHER | 20 | ||
| 37 | 23B0012 | TAP.ROLLER BRG 32216 | 2 | ||
| 38 | 41C0264 | BUSHING | 1 | ||
| 40 | 23B0018 | TAP.ROLLER BRG 31311 | 1 | ||
| 41 | 12B0105 | O-RING | 1 | ||
| 43 | 71A0831 | DIFF HOUSING | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 01C0004 | TUBE | 8 | ||
| 2 | 02A0009 | TEE | 4 | ||
| 3 | 05C0628 | OIL PIPE | 1 | ||
| 4 | 06B0006 | WASHER | 2 | ||
| 5 | 00B0020 | BOLT | 2 | ||
| 6 | 16A1000 | TEE | 2 | ||
| 7 | 05C0629 | OIL PIPE | 1 | ||
| 8 | 01C0005 | OIL PIPE | 1 | ||
| 9 | 05A0557 | PLUG | 2 | ||
| 10 | 01C0006 | OIL PIPE | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 16 | 07C1584 | HOSE AS | 1 | ||
| 17 | 22A1605 | BRACKET | 1 | ||
| 18 | 00B0002 | BOLT | 2 | ||
| 19 | 02C0911 | FIILLER TUBE | 1 | ||
| 21 | 31C0173 | CONNECTOR | 1 | ||
| 22 | 01B0298 | BOLT | 2 | ||
| 23 | 03B0205 | LOCKNUT | 2 | ||
| 24 | 06B0016 | WASHER | 2 | ||
| 25 | 17B0019 | CUSHION | 2 |
1100-1300 руб. |
|
| 26 | 17B0017 | CUSHION |
|
2 |
150-180 руб. |
| 27 | 12A0004 | SHIM | 2 | ||
| 28 | 05D0001 | BRACKET | 2 | ||
| 29 | 00B0016 | BOLT | 8 | ||
| 30 | 06B0014 | WASHER | 8 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 05B0024 | STUD | 4 | ||
| 2 | 03B0173 | NUT | 4 | ||
| 3 | 06B0008 | WASHER |
|
4 |
20-30 руб. |
| 4 | 80A0009 | GASKET | 1 | ||
| 5 | 03A0002 | FLANGE | 1 | ||
| 6 | 57A0008 | SHIM | 1 | ||
| 7 | 40A0032 | SHAFT GEAR | 1 | ||
| 8 | 40A0027 | SHAFT GEAR | 1 | ||
| 9 | 42C0353 | TRANSMISSION | 1 | ||
| 10 | 12C2510 | SHIFT CONTROL VALVE (S.C.: Z) | 1 | ||
| 11 | 11C0718 | GEAR SHIFT PUMP (S.C.: Z) |
|
1 |
15000-17000 руб. |
| 12 | 52C0002 | TORQUE CONVERTER (S.C.: Z) | 1 | ||
| 13 | 04A0012 | FLANGE | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 01B0100 | BOLT | 4 | ||
| 2 | 06B0002 | WASHER | 4 | ||
| 3 | 12B0076 | O-RING | 1 | ||
| 4 | 10D0525 | PIPE | 1 | ||
| 5 | 03B0003 | NUT | 2 | ||
| 6 | 01B0175 | BOLT | 2 | ||
| 7 | 06B0008 | WASHER |
|
2 |
20-30 руб. |
| 8 | 02C0017 | PIPE | 1 | ||
| 9 | 72A0041 | SPLIT FLANGE | 2 | ||
| 10 | 00B0025 | BOLT | 12 | ||
| 11 | 06B0013 | WASHER | 12 | ||
| 12 | 12B0302 | O-RING | 3 | ||
| 13 | 07C2021 | HOSE AS | 1 | ||
| 14 | 07C0009 | HOSE | 1 | ||
| 15 | 09C0779 | CLAMP | 1 | ||
| 16 | 10D3710 | TUBE AS | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 12B0181 | O-RING | 2 | ||
| 2 | 04A1846 | FLANGE | 2 | ||
| 3 | 04B0156 | SCREW | 8 | ||
| 4 | 06B0002 | WASHER | 8 | ||
| 5 | 30C1742 | CONNECTOR | 2 | ||
| 6 | 03B0093 | PLUG | 2 | ||
| 7 | 12B0351 | O-RING | 2 | ||
| 8 | 30C1741 | CONNECTOR | 2 | ||
| 9 | 06C4269 | HOSE AS | 1 | ||
| 10 | 06C6697 | HOSE AS | 1 | ||
| 11 | 31C0006 | CONNECTOR (S.C.: Z) | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 06C4570 | HOSE AS | 1 | ||
| 2 | 12B0251 | O-RING | 2 | ||
| 3 | 06C4571 | HOSE AS | 1 | ||
| 4 | 09C0110 | CLAMP | 1 | ||
| 5 | 20A1710 | PLATE | 2 | ||
| 6 | 03B0003 | NUT | 5 | ||
| 7 | 01B0217 | BOLT | 2 | ||
| 8 | 06B0008 | WASHER |
|
15 |
20-30 руб. |
| 9 | 00B0011 | BOLT | 2 | ||
| 10 | 23A6597 | BRACKET | 1 | ||
| 11 | 31C0005 | CONNECTOR (S.C.: Z) | 3 | ||
| 12 | 12C2394 | FLOW ANPLIFYING VAVLE (S.C.: Z) | 1 | ||
| 13 | 01B0283 | BOLT | 3 | ||
| 14 | 06B0007 | WASHER |
|
3 |
10-20 руб. |
| 15 | 72A0027 | PLATE | 2 | ||
| 16 | 06B0002 | WASHER | 12 | ||
| 17 | 00B0019 | BOLT | 12 | ||
| 18 | 72A0010 | PLATE | 2 | ||
| 19 | 00B0017 | BOLT |
|
8 |
80-90 руб. |
| 20 | 12B0287 | O-RING | 3 | ||
| 21 | 07C1582 | HOSE AS | 1 | ||
| 22 | 07C1581 | HOSE AS | 1 | ||
| 23 | 72A0035 | SPLIT FLANGE | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 44C0668 | STEERING COLUMN AS (S.C.: Z) | 1 | ||
| 2 | 06C5945 | HOSEAS | 1 | ||
| 3 | 12C0014 | PRESSURE REDUCING VALVE (S.C.: Z) | 1 | ||
| 4 | 06C4276 | HOSE AS | 1 | ||
| 5 | 06C5947 | HOSEAS | 1 | ||
| 6 | 06C5946 | HOSEAS | 1 | ||
| 7 | 06C4272 | HOSE AS | 1 | ||
| 8 | 06C4565 | HOSE AS | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 07C0012 | SUCTION HOSE | 1 | ||
| 2 | 15B0102 | CLAMP | 2 | ||
| 3 | 10D0052 | SUCTION TUBE | 1 | ||
| 4 | 12B0303 | O-RING | 1 | ||
| 5 | 01B0160 | BOLT | 4 | ||
| 6 | 06B0008 | WASHER |
|
8 |
20-30 руб. |
| 7 | 11C0007 | GEAR PUMP | 1 | ||
| 8 | 11C0009 | GEAR PUMP | 1 | ||
| 9 | 00B0017 | BOLT |
|
4 |
80-90 руб. |
| 10 | 72A0003 | SPLIT FLANGE |
|
1 |
6000-7000 руб. |
| 11 | 10D4665 | TUBE AS | 1 | ||
| 12 | 12B0302 | O-RING | 1 | ||
| 13 | 35C0800 | SUCTION HOSE | 1 | ||
| 14 | 15B0027 | CLAMP | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 07C0007 | HOSE | 1 | ||
| 2 | 02C0011 | PIPE | 1 | ||
| 3 | 06C0022 | HOSE | 1 | ||
| 4 | 22C0006 | BRACKET | 1 | ||
| 5 | 00B0019 | BOLT | 12 | ||
| 6 | 72A0035 | SPLIT FLANGE | 2 | ||
| 7 | 06B0002 | WASHER | 20 | ||
| 8 | 10D7420 | TUBE AS | 1 | ||
| 9 | 12B0287 | O-RING | 2 | ||
| 10 | 10D7434 | TUBE AS | 1 | ||
| 13 | 03B0093 | PLUG | 2 | ||
| 14 | 12B0351 | O-RING | 2 | ||
| 16 | 06B0030 | WASHER | 8 | ||
| 17 | 29A1553 | PLATE | 2 | ||
| 18 | 03B0053 | NUT | 4 | ||
| 19 | 88A0208 | U-BOLT | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 00B0033 | BOLT | 8 | ||
| 2 | 06B0008 | WASHER |
|
8 |
20-30 руб. |
| 3 | 10D3678 | TUBE AS | 1 | ||
| 4 | 12B0287 | O-RING | 6 | ||
| 5 | 10D3666 | TUBE AS | 1 | ||
| 6 | 10D3865 | TUBE AS | 1 | ||
| 7 | 10D3866 | TUBE AS | 1 | ||
| 8 | 23A7235 | PLATE | 1 | ||
| 9 | 00B0019 | BOLT | 20 | ||
| 10 | 06B0002 | WASHER | 36 | ||
| 11 | 06B0030 | WASHER | 28 | ||
| 12 | 14A6920 | PLATE | 2 | ||
| 13 | 03B0053 | NUT | 8 | ||
| 14 | 88A0208 | U-BOLT | 4 | ||
| 15 | 72A0035 | SPLIT FLANGE | 2 | ||
| 16 | 10D4176 | TUBE AS | 1 | ||
| 17 | 10D4177 | TUBE AS | 1 | ||
| 18 | 07C1697 | HOSE AS | 4 | ||
| 19 | 00B0018 | BOLT | 8 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 07C0008 | HOSE Ф25 | 4 | ||
| 2 | 06B0002 | WASHER | 12 | ||
| 3 | 01B0100 | BOLT | 8 | ||
| 4 | 12B0287 | O-RING | 2 | ||
| 5 | 10D0049 | PIPE | 2 | ||
| 6 | 02C0014 | PIPE | 1 | ||
| 7 | 02C0013 | PIPE | 1 | ||
| 8 | 21A1205 | CLAMP | 4 | ||
| 9 | 00B0019 | BOLT | 4 | ||
| 10 | 02C0009 | PIPE | 1 | ||
| 11 | 02C0010 | PIPE | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 06B0008 | WASHER |
|
8 |
20-30 руб. |
| 2 | 00B0035 | BOLT | 8 | ||
| 3 | 72A0003 | SPLIT FLANGE |
|
2 |
6000-7000 руб. |
| 4 | 04A1545 | FLANGE | 1 | ||
| 5 | 12B0299 | O-RING | 3 | ||
| 6 | 12B0292 | O-RING | 1 | ||
| 7 | 00A0676 | CONNECTOR | 1 | ||
| 8 | 12C1008 | CHECK VALVE (S.C.: Z) | 1 | ||
| 9 | 12B0268 | O-RING | 2 | ||
| 10 | 00A0699 | CONNECTOR | 2 | ||
| 11 | 37B0010 | CABLE TIE | 2 | ||
| 12 | 07C2477 | HOSE AS | 1 | ||
| 13 | 12B0224 | O-RING | 2 | ||
| 14 | 07C2478 | HOSE AS | 1 | ||
| 15 | 00A0114 | CONNECTOR | 2 | ||
| 16 | 06B0189 | WASHER | 4 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 07B0005 | SNAP RING | 1 | ||
| 2 | 78A0002 | VALVE BLOCK | 1 | ||
| 3 | 55A0056 | VALVE BUSHING | 1 | ||
| 4 | 65A0488 | SPOOL | 1 | ||
| 5 | 39A0314 | PIPE | 1 | ||
| 6 | 75A0173 | SPRING | 1 | ||
| 7 | 76A0008 | SNAP RING | 1 | ||
| 8 | 03B0032 | NUT | 1 | ||
| 9 | 08B0010 | PIN | 1 | ||
| 10 | 65A0203 | SCREW ROD | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 00B0038 | BOLT | 5 | ||
| 2 | 06B0013 | WASHER | 5 | ||
| 3 | 06B0009 | WASHER | 5 | ||
| 4 | 01B0244 | BOLT | 1 | ||
| 5 | 12B0356 | O-RING | 2 | ||
| 6 | 03A0067 | CONNECTOR | 1 | ||
| 7 | 10D5606 | TUBE AS | 1 | ||
| 8 | 10D5781 | TUBE AS | 1 | ||
| 9 | 13C0373 | AIR RESERVOIR (S.C:Z) | 1 | ||
| 10 | 13C0374 | COMBINATION VALVE(S.C:Z) | 1 | ||
| 11 | 00D9207 | BRACKET | 1 | ||
| 12 | 05C4954 | HOSE AS | 1 | ||
| 13 | 00B0007 | BOLT | 2 | ||
| 14 | 20A9537 | CLAMP | 5 | ||
| 15 | 06B0006 | WASHER | 10 | ||
| 16 | 10D5473 | TUBE AS | 1 | ||
| 17 | 30A1910 | HOSE | 1 | ||
| 18 | 09C0235 | CLAMP | 2 | ||
| 19 | 00C2516 | ASSISTOR & LINES (S.C:Z) | 1 | ||
| 20 | 13C0515 | BRAKE VALVE AS | 1 | ||
| 21 | 04C0314 | HOSE | 1 | ||
| 22 | 06B0117 | WASHER | 14 | ||
| 23 | 03C0002 | HOSE | 1 | ||
| 24 | 11B0011 | NYLON HOSE | 1 | ||
| 25 | 22A4273 | PLATE | 1 | ||
| 26 | 04C0421 | HOSE AS | 1 | ||
| 27 | 14A9143 | PLATE | 2 | ||
| 28 | 00B0075 | BOLT | 8 | ||
| 29 | 37B0004 | NYLON STRAP | 3 | ||
| 30 | 04C0419 | HOSE AS | 1 | ||
| 31 | 04C0443 | HOSE AS | 1 | ||
| 32 | 04C0420 | HOSE AS | 1 | ||
| 33 | 13C0514 | ASSISTOR | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 05C3965 | HOSE AS | 1 | ||
| 2 | 06B0013 | WASHER | 5 | ||
| 3 | 06B0009 | WASHER | 5 | ||
| 4 | 00B0038 | BOLT | 5 | ||
| 5 | 29A3629 | PLATE | 1 | ||
| 6 | 13C0514 | ASSISTOR | 1 | ||
| 7 | 03B0436 | NUT | 2 | ||
| 8 | 00B0005 | BOLT | 2 | ||
| 9 | 06B0002 | WASHER | 2 | ||
| 10 | 09C0466 | CLAMP | 2 | ||
| 12 | 04C0389 | HOSE AS | 1 | ||
| 13 | 06B0117 | WASHER | 2 | ||
| 14 | 30A1910 | HOSE | 1 | ||
| 15 | 09C0235 | CLAMP | 2 | ||
| 16 | 12B0356 | O-RING | 2 | ||
| 17 | 03A0067 | CONNECTOR | 1 | ||
| 18 | 01B0244 | BOLT | 1 | ||
| 19 | 00A0050 | CONNECTOR | 1 | ||
| 20 | 06B0053 | WASHER | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 13C0008 | BRAKE (S.C.: Z) |
|
1 |
10000-11000 руб. |
| 2 | 13C0009 | AIR CHAMBER AS (S.C.: Z) |
|
1 |
18000-21000 руб. |
| 3 | 00A0080 | CONNECTOR | 1 | ||
| 4 | 03B0115 | PLUG | 1 | ||
| 5 | 13C0025 | PARKING BRAKE VALVE | 1 | ||
| 6 | 24C0008 | LINKAGE(S.C.: Z) | 1 | ||
| 8 | 03C0040 | NYLON HOSE | 1 | ||
| 10 | 00A1201 | CONNECTOR | 2 | ||
| 11 | 06B0053 | WASHER | 3 | ||
| 12 | 13C0012 | VALVE | 1 | ||
| 14 | 30C0283 | CONNECTOR | 1 | ||
| 16 | 00A0034 | CONNECTOR | 1 | ||
| 18 | 53A0049 | FLANGE | 1 | ||
| 19 | 72A0036 | LINKAGE | 1 | ||
| 20 | 11B0011 | NYLON HOSE | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 46C4659 | A/C GP-CAB (S.C.: Z) | 1 | ||
| 2 | 21A8906 | MOUNTING PLATE | 2 | ||
| 3 | 46C2543 | CONDENSER (S.C.: Z) | 1 | ||
| 4 | 00B0075 | BOLT | 16 | ||
| 5 | 06B0005 | WASHER | 16 | ||
| 6 | 06B0006 | WASHER | 16 | ||
| 7 | 46C4666 | HOSE | 1 | ||
| 8 | 46C0824 | SOLENOID VALVE AS | 1 | ||
| 9 | 46C1249 | HOSE | 1 | ||
| 10 | 09C1018 | DOUBLE CLAMP | 1 | ||
| 11 | 00B0011 | BOLT | 1 | ||
| 12 | 06B0007 | WASHER |
|
1 |
10-20 руб. |
| 13 | 06B0008 | WASHER |
|
1 |
20-30 руб. |
| 14 | 21A6916 | PLATE | 1 | ||
| 15 | 46C5875 | HOSE | 1 | ||
| 16 | 09C0126 | DOUBLE CLAMP | 4 | ||
| 17 | 46C0486 | WATER INTAKE VALVE | 2 | ||
| 18 | 46C0010 | V-BELT | 1 | ||
| 19 | 71A0921 | COMPRESSOR BRACKET | 1 | ||
| 20 | 46C0110 | COMPRESSOR | 1 |
41000-48000 руб. |
|
| 21 | 03B0021 | NUT | 7 | ||
| 22 | 21A7827 | PLATE | 1 | ||
| 24 | 00B0010 | BOLT | 2 | ||
| 25 | 06B0024 | WASHER | 4 | ||
| 26 | 06B0003 | WASHER | 4 | ||
| 27 | 03B0036 | NUT | 2 | ||
| 28 | 21A6917 | PLATE | 1 | ||
| 29 | 00B0169 | BOLT | 2 | ||
| 30 | 09C0125 | CLAMP | 2 | ||
| 31 | 00B0128 | BOLT | 2 | ||
| 32 | 03B0003 | NUT | 1 | ||
| 33 | 01B0286 | BOLT | 1 | ||
| 34 | 06B0012 | WASHER | 1 | ||
| 35 | 06B0015 | WASHER | 1 | ||
| 36 | 03B0095 | NUT | 1 | ||
| 37 | 12A0238 | SUPPORT PLATE | 2 | ||
| 38 | 06B0002 | WASHER | 6 | ||
| 39 | 06B0001 | WASHER | 6 | ||
| 40 | 03B0053 | NUT | 6 | ||
| 41 | 00B0002 | BOLT | 4 | ||
| 42 | 16A0072 | BLOCK | 1 | ||
| 43 | 06B0013 | WASHER | 2 | ||
| 44 | 06B0009 | WASHER | 2 | ||
| 45 | 03B0111 | NUT | 2 | ||
| 46 | 05B0199 | SCREW ROD | 1 | ||
| 47 | 00B0083 | BOLT | 1 |
