| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | GB5782 M12×40 | Bolt M12×40 | 4 | ||
| 2 | 403302X7 | Locking plate | 2 | ||
| 3 | 403303X7 | Press plate | 2 | ||
| 4 | 403301X9C | Flange | 1 | ||
| 5 | 403315 | O-ring |
|
2 |
250-290 руб. |
| 6 | 403316 | Oil seal seat | 2 | ||
| 7 | GB13871.1 | Frame oil seal | 4 | ||
| 7 | FB70×95×12 | FB70×95×12 | 1 | ||
| 8 | GB893.1 130 | Circlip for hole 130 | 2 | ||
| 9 | GB3452.1 125×2.65 | O-ring 125×2.65 | 4 | ||
| 10 | GB893.1 130 | Circlip for hole -A130 | 2 | ||
| 11 | GB276 6312 | Ball bearing 6312 | 3 | ||
| 12 | 403310X3 | Slide bushing | 1 | ||
| 13 | 403311 | Output gear | 1 | ||
| 14 | 403309×7 | Output shaft | 1 | ||
| 15 | 403305A | Distance sleeve | 1 | ||
| 16 | 409109×9C | Flange | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | GB276 6210NR | Bearing 6210NR | 1 | ||
| 2 | BD15-00011A | Gear | 1 | ||
| 2 | BD15-00012B | Gear | 1 | ||
| 3 | GB276 6211 | Bearing 6211 | 1 | ||
| 4 | BD15-00013A | Bearing base | 1 | ||
| 5 | BD15-00010 | Gasket | 1 | ||
| 6 | BD15-00005A | Housing | 1 | ||
| 7 | 04530-12035 | Screw M20 | 2 | ||
| 8 | BD15-07000 | Breather assembly | 1 | ||
| 9 | YB315Z5-15 | Plug | 1 | ||
| 10 | BD15-00017 | Pin | 1 | ||
| 11 | YB315Z5-14S | Pipe connector | 4 | ||
| 12 | YB315Z5-09 | Combined washer | 4 | ||
| 13 | BD15-11000 | Transmission pump | 1 | ||
| 14 | 01602-11030 | Washer 10 | 61 | ||
| 15 | 01010-81055 | Bolt M10×55 | 6 | ||
| 16 | 01010-81070 | Bolt M10×70 | 20 | ||
| 17 | BD15-00007 | Gasket | 1 | ||
| 18 | BD15-00018 | Gasket | 1 | ||
| 19 | BD15-09000 | Transmission control valve | 1 | ||
| 20 | BD15-00019 | Pin | 1 | ||
| 21 | 01010-81840 | Bolt M18×40 | 8 | ||
| 22 | 01602-11854 | Washer 18 | 8 | ||
| 23 | BD15-10000 | Support | 2 | ||
| 24 | 04418-03060 | Rivet | 4 | ||
| 25 | BD15-00025A | Nameplate | 1 | ||
| 26 | 1305C-010 | Oil Plug R1/4 | 1 | ||
| 27 | BD15-06004 | Gasket | 2 | ||
| 28 | BD15-06100 | Filter module | 1 | ||
| 29 | BD15-06200 | Crust module | 1 | ||
| 30 | 01010-81030 | Bolt M10×30 | 40 | ||
| 31 | GB276 6012 | Bearing 6012 | 1 | ||
| 32 | BD15-00006A | Shaft gear | 1 | ||
| 33 | GB276 6210NR | Bearing 6210NR | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | 01016-81030 | Bolt M10×30 | 8 | ||
| 2 | 01602-11030 | Washer 10 | 8 | ||
| 3 | BD15-00009 | Cover | 1 | ||
| 4 | 07042-00211 | Plug screw | 1 | ||
| 5 | 07000-72020 | O-ring 20×2.4 | 1 | ||
| 6 | BD15-00008 | Gasket | 1 | ||
| 7 | BD15-00014/15/16 | Adjusting gasket (optional) | 1 | ||
| 8 | GB5785 M12×1.25×100 | Bolt M12×1.25×100 | 12 | ||
| 9 | GB276 6411 | Bearing 6411 | 1 | ||
| 10 | 04020-01030 | Pin | 2 | ||
| 11 | BD15-01004 | Seal | 1 | ||
| 12 | BD15-03004 | Lock shim | 6 | ||
| 13 | BD15-03008 | Cylinder body | 1 | ||
| 14 | BD15-03009A | Mid-shaft output gear | 1 | ||
| 15 | BD15-03006 | Piston | 1 | ||
| 16 | BD15-01003 | Seal 70×78×5 | 1 | ||
| 17 | BD15-03005 | Spring | 1 | ||
| 18 | 04064-06525 | Circlip 65 |
|
1 |
140-160 руб. |
| 19 | BD15-03011 | Ring gear Ⅱ | 1 | ||
| 20 | 01602-11030 | Washer 10 | 14 | ||
| 21 | 01010-81020 | Bolt M10×20 | 12 | ||
| 22 | BD15-03100 | Driving disc | 2 | ||
| 23 | GB276 6204 | Bearing 6204 | 1 | ||
| 24 | BD15-03003 | Passive disc Ⅱ | 1 | ||
| 25 | BD15-03010 | Pin | 1 | ||
| 26 | BD15-03002 | Pressing pan | 1 | ||
| 27 | GB276 6022 | Bearing 6022 | 1 | ||
| 28 | BD15-03007 | Seal | 1 | ||
| 29 | BD15-03001 | Shaft | 1 | ||
| 30 | GB5785 M12×1.5×30 | Bolt M12×1.5×30 | 8 | ||
| 31 | 01602-11236 | Washer 12 | 8 | ||
| 32 | BD15-12000 | Brake assembly | 1 | ||
| 33 | 01010-81035 | Nut M10×35 | 2 | ||
| 34 | BD15-00024 | Brake joint | 1 | ||
| 35 | 01580-01008 | Nut M10 | 2 | ||
| 36 | BD15-04009 | Flange | 1 | ||
| 37 | BD15-04001 | Lock nut | 2 | ||
| 38 | BD15-04010 | Press plate | 1 | ||
| 39 | BD15-04008 | Security cover | 1 | ||
| 40 | BD15-04003 | Seal base | 2 | ||
| 41 | 07000-05120 | O-ring 130×5.7 | 4 | ||
| 42 | GB893.1 130×3 | Circlip 130×3 | 2 | ||
| 43 | 07012-00070 | Seal 70×95×12 | 4 | ||
| 44 | GB276 6312 | Bearing 6312 | 2 | ||
| 45 | BD15-04007 | Shaft sleeve | 1 | ||
| 46 | BD15-04004 | Output shaft | 1 | ||
| 47 | GB3452.3 42.5×5.3 | O-ring 42.5×5.3 | 1 | ||
| 48 | BD15-04006A | Output gear | 1 | ||
| 49 | BD15-04005 | Separate cover | 1 | ||
| 50 | GB276 6410 | Bearing 6410 | 1 | ||
| 51 | BD15-04002 | Flange | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 010 | 4644 303 216 | Output Shaft |
|
1 |
12000-14000 руб. |
| 020 | 4644 303 226 | Output Gear | 1 | ||
| 030 | 0635 416 285 | Cylinder Bearing NJ213EC3 |
|
1 |
4100-4800 руб. |
| 034 | 1204 308 062 | Adjusting Shim | 1 | ||
| 040 | 4620 303 247 | Press Plate |
|
2 | |
| 050 | 0636 015 127 | Bolt M10×30 | 4 | ||
| 060 | 1269 302 164 | Bolt Locking Plate |
|
2 |
410-480 руб. |
| 070 | 0750 111 116 | Shaft Gasket | 2 | ||
| 080 | 0750 116 134 | Ball Bearing 6311C3 |
|
1 |
1400-1600 руб. |
| 090 | 0630 502 048 | Hole Collar 120×4 | 3 | ||
| 100 | 0769 120 338 | Adjusting Shim | 1 | ||
| 110 | 0730 062 296 | Axle Bush |
|
1 |
2100-2400 руб. |
| 140 | 4644 303 389 | Output Flange AD=150 | 1 | ||
| 190 | 0636 021 150 | Bolt M12×1.5×40 | 8 | ||
| 192 | 0637 106 095 | Nut M12×1.5 | 8 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 010 | 0501 003 822 | Brake Module | 1 | ||
| 100 | 4644 309 002 | Brake Strake | 1 | ||
| 110 | 4644 309 808 | Detent Flange | 1 | ||
| 120 | 0636 021 151 | Bolt M14×1.5×45 | 8 | ||
| 125 | 0637 106 098 | Nut M14×1.5 | 8 | ||
| 140 | 0636 015 166 | Bolt M10×25 | 8 | ||
| 150 | 0630 001 014 | Washer 10.5 | 8 | ||
| 160 | 4644 309 008 | Locating Plate | 1 | ||
| 230 | 4644 309 066 | Washer | 1 | ||
| 240 | 0730 107 676 | Washer | 1 | ||
| 244 | 0630 101 014 | Washer 10.5 | 2 | ||
| 248 | 0636 010 159 | Washer M10×40 | 1 | ||
| 250 | 0636 015 115 | Washer M10×22 | 1 | ||
| 254 | 0630 503 016 | Stop Ring | 1 | ||
| 260 | 0634 306 017 | O-ring 17.3×2.4 | 1 | ||
| 270 | 0634 306 024 | O-ring 25.3×2.4 | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 010 | 4644 221 877H | Oil Suction Pipe | 1 | ||
| 020 | 4644 221 821 | Oil Suction Pipe |
|
1 | |
| 030 | 4644 321 244 | Paper Washer |
|
2 |
340-400 руб. |
| 050 | 0636 010 089 | Bolt M8×50 | 4 | ||
| 070 | 0634 801 050 | Copper Washer |
|
20 |
40-50 руб. |
| 080 | 0501 204 425 | Tube | 1 | ||
| 100 | 0501 204 674 | Tube |
|
1 |
1800-2100 руб. |
| 110 | 0501 204 425 | Tube | 1 | ||
| 120 | 0501 204 422 | Tube | 1 | ||
| 130 | 0501 204 427 | Tube |
|
1 | |
| 140 | 0501 204 427 | Tube |
|
1 | |
| 170 | 0637 842 509 | Pipe Junction | 4 | ||
| 250 | 0737 835 153 | Hollowness Bolt |
|
8 |
230-270 руб. |
| 320 | 4642 331 216 | Paper Washer |
|
1 |
360-420 руб. |
| 614 | 0636 101 031 | Bolt | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 010 | 4642 231 914 | Oil Filling Pipe | 1 | ||
| 030 | 4642 331 216 | Paper Washer |
|
3 |
360-420 руб. |
| 040 | 0636 015 077 | Bolt M8×20 | 2 | ||
| 060 | 4644 231 100 | Oil Scale Ruler | 1 | ||
| 080 | 4642 331 056 | Back Plate | 1 | ||
| 130 | 4644 301 016 | Cover | 1 | ||
| 150 | 0636 015 289 | Bolt | 2 | ||
| 160 | 0636 305 016 | Plug Screw AM22×1.5 | 1 | ||
| 170 | 0634 801 074 | Washer A22×27 | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 010 | 4644 355 864 | Chelse Shaft | 1 | ||
| 020 | 4644 311 008 | Drive Gear |
|
1 |
9000-10000 руб. |
| 030 | 0630 513 068 | Circlip for Axial |
|
1 |
120-140 руб. |
| 040 | 0635 303 104 | Ball bearing HK4516 |
|
1 |
900-1100 руб. |
| 050 | 0630 513 016 | Circlip for Hole |
|
1 |
120-140 руб. |
| 060 | 0750 116 259 | Ball bearing 6209N/C3 |
|
1 |
1300-1500 руб. |
| 070 | 0630 503 011 | Circlip for Axial |
|
2 |
190-220 руб. |
| 080 | 0630 501 033 | Circlip for Axial 45×1.75 |
|
1 |
270-320 руб. |
| 100 | 4644 311 121 | Pump Flange | 1 | ||
| 105 | 4644 311 913 | Transition Disk | 1 | ||
| 110 | 4644 311 209 | Paper Washer |
|
1 |
270-320 руб. |
| 115 | 4644 311 911 | Paper Washer | 1 | ||
| 120 | 0636 015 077 | Bolt M8×20 | 8 | ||
| 140 | 0501 205 628 | Hose | 1 | ||
| 150 | 4642 211 001 | Oil Pipe Unit |
|
1 |
12000-14000 руб. |
| 160 | 0637 835 003 | Hollowness Bolt A8 | 1 | ||
| 170 | 0634 801 038 | Red Copper Washer A14×28 | 4 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 010 | 4644 302 188 | Turboshaft |
|
1 |
17000-19000 руб. |
| 012 | 0631 329 267 | Elastic Pin 2.5×5 | 1 | ||
| 014 | 0631 329 124 | Elastic Pin 1.5×5 | 1 | ||
| 020 | 0750 116 139 | Ball Bearing 6308C3 |
|
1 |
1400-1700 руб. |
| 030 | 0769 120 427 | Adjusting Shim | 1 | ||
| 040 | 0630 501 031 | Elastic Tollar 40×1.75 |
|
1 |
140-160 руб. |
| 050 | 4644 302 016 | Input Gear | 1 | ||
| 060 | 0750 118 200 | Cylinder Bearing NJ209E/C3 |
|
1 |
2700-3200 руб. |
| 070 | 0734 317 252 | Ring Seal |
|
1 |
900-1100 руб. |
| 080 | 4644 302 250 | Flange |
|
1 |
39000-46000 руб. |
| 090 | 4644 302 211 | Paper Cushion |
|
1 |
500-600 руб. |
| 100 | 4642 301 136 | Bearing Block |
|
1 |
16000-19000 руб. |
| 110 | 4644 301 262 | Paper Cushion |
|
1 |
650-750 руб. |
| 120 | 0636 015 092 | Bolt M8×28 | 8 | ||
| 130 | 0734 401 078 | Ring Seal |
|
1 |
900-1100 руб. |
| 140 | 0735 298 027 | Needle Bearing HK75×83×16 |
|
1 |
3800-4500 руб. |
| 150 | 0750 111 231 | Shaft Gasket | 1 | ||
| 160 | 4644 311 893 | Service Drive Shaft |
|
1 |
8000-9500 руб. |
| 170 | 0634 402 025 | Ring Seal |
|
1 |
600-700 руб. |
| 180 | 4644 301 265 | Paper Cushion |
|
1 |
360-420 руб. |
| 184 | 0501 208 765 | Pump | 1 | ||
| 186 | 0750 116 104 | Ball Bearing 6206RS |
|
1 |
1100-1300 руб. |
| 190 | 0631 501 514 | Flat Key A6×6×28 | 1 | ||
| 194 | 0750 116 104 | Ball Bearing 6206RS |
|
1 |
1100-1300 руб. |
| 200 | 0636 010 111 | Bolt M8×85 | 4 | ||
| 210 | 0636 010 123 | Bolt M8×115 | 4 | ||
| 220 | 0630 501 024 | Shaft Collar 30×1.5 |
|
2 |
140-160 руб. |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 0 | 50M.01 | Main transimission assembly | 1 | ||
| 1 | 50M.01-01 | Locknut | 1 | ||
| 2 | 50M.01-02 | Washer | 1 | ||
| 3 | 50M.01-24 | O seal ring | 1 | ||
| 4 | 50M.01.01-01 | Flange | 1 | ||
| 5 | GB5785 M12×1.5×55 | Bolt M12×1.5×55 | 1 | ||
| 6 | GB93-12 | Washer 12 | 1 | ||
| 7 | GB13871 FB80×100×10 | Oil seal FB80×100×10 | 1 | ||
| 8 | GB13871 B80×100×10 | Oil seal B80×100×10 | 1 | ||
| 9 | 50M.01-03 | Sealing gland | 1 | ||
| 10 | GB297 31313 | Bearing 31313 | 1 | ||
| 11 | 50M.01-04 | Bearing bushing | 1 | ||
| 12 | 50M.01-05 | Adjusting washer (1 set) | 1 | ||
| 13 | 50M.01-06 | Shaft bushing | 1 | ||
| 14 | GB297 31314 | Bearing 31314 | 1 | ||
| 15 | 50M.01-23 | Adjusting washer (1 set) | 1 | ||
| 16 | 50M.01-20 | Adjusting nut | 2 | ||
| 17 | Inch 47686/47620A | Bearing | 2 | ||
| 18 | 50M.01-17 | Differential bolt | 8 | ||
| 19 | 50M.01-12 | Nut M14×1.5 | 12 | ||
| 20 | 50M.01-11B | Differential cage | 1 | ||
| 21 | 50M.01-14A/B | Driven bevel gear | 1 | ||
| 22 | 50M.01-13 | Bolt | 12 | ||
| 23 | 50L.01-11 | Washer for bevel gear | 4 | ||
| 24 | 50L.01-19 | Differential crossing | 1 | ||
| 25 | 50M.01-16 | Bevel gear | 4 | ||
| 26 | 50M.01-19 | Bearing seat | 2 | ||
| 27 | 50M.01-10 | Bolt for main reductor | 4 | ||
| 28 | 404319B | Lock plate | 2 | ||
| 29 | GB93-10 | Washer 10 | 2 | ||
| 30 | GB32.2 M10×1×20 | Bolt M10×1×20 | 2 | ||
| 31 | Φ1.5X450 | Iron wire | 2 | ||
| 32 | 50M.01-18 | Nut M16×1.5 | 8 | ||
| 33 | 50M.01-21 | Differential cage | 1 | ||
| 34 | 50M.01-09B | Thrust washer | 2 | ||
| 35 | 50M.01-22 | Axle shaft gear | 2 | ||
| 36 | 50M.01-08 | Differential cage | 1 | ||
| 37 | 50L.01.03 | Bolt | 1 | ||
| 38 | 50L.01-23 | Lock plate | 1 | ||
| 39 | GB6173 M27×2 | Nut M27×2 | 1 | ||
| 40 | NJ2307ENVX3 | Bearing | 1 | ||
| 41 | GB305 90/96.5 | Stop ring 90/96.5 | 1 | ||
| 42 | 50M.01-07A/B | Driving bevel gear | 1 | ||
| 43 | GB93-14 | Washer 14 | 7 | ||
| 44 | GB5785 M14×1.5×55 | Bolt M14×1.5×55 | 7 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 0 | 461-18-01000 | Main transmission assembly | 1 | ||
| 1 | 461-18-01001 | Lock nut | 1 | ||
| 2 | 461-18-01002 | Washer | 1 | ||
| 3 | 461-18-01032 | O-seal ring | 1 | ||
| 4 | 461-18-01101 | Flange | 1 | ||
| 5 | GB5785 M12X1.5X55 | Bolt M12X1.5X55 | 1 | ||
| 6 | 01602-21236 | Washer 12 |
|
1 | |
| 7 | GB13871 FB80X100X10 | Oil seal FB80X100X10 | 1 | ||
| 8 | GB13871 B80X100X10 | Oil seal B80X100X10 | 1 | ||
| 9 | 461-18-01003 | Sealing gland | 1 | ||
| 10 | GB297 31313 | Bearing 31313 | 1 | ||
| 11 | 461-18-01004 | Bearing bushing | 1 | ||
| 12 | 461-18-01005/6/7 | Adjusting washer (1 set) | 1 | ||
| 13 | 461-18-01008 | Shaft bushing | 1 | ||
| 14 | GB297 31314 | Bearing 31314 | 1 | ||
| 15 | 461-18-01029/30/31 | Adjusting washer (1 set) | 1 | ||
| 16 | 461-18-01025 | Adjusting nut | 2 | ||
| 17 | Inch 47686/47620A | Bearing | 2 | ||
| 18 | 461-18-01021 | Differential bolt | 8 | ||
| 19 | 461-18-01016 | Nut M14X1.5 | 12 | ||
| 20 | 461-18-01015 | Differential cage | 1 | ||
| 21 | 461-18-01018 | Driven bevel gear | 1 | ||
| 22 | 461-18-01017 | Bolt | 12 | ||
| 23 | 461-18-01019 | Washer for bevel gear | 4 | ||
| 24 | 461-18-01028 | Differential crossing | 1 | ||
| 25 | 461-18-01020 | Bevel gear | 4 | ||
| 26 | 461-18-01023 | Bearing seat | 2 | ||
| 27 | 461-18-01013 | Bolt | 4 | ||
| 28 | 461-18-01009 | Lock plate | 2 | ||
| 29 | 01602-21030 | Washer 10 |
|
2 |
40-50 руб. |
| 30 | 01014-81020 | Bolt M10X1X20 | 2 | ||
| 31 | 461-18-01014 | Iron wire Φ3.2X450 | 2 | ||
| 32 | 461-18-01022 | Nut M16X1.5 | 8 | ||
| 33 | 461-18-01026 | Differential cage | 1 | ||
| 34 | 461-18-01012 | Thrust washer | 2 | ||
| 35 | 461-18-01027 | Axle shaft gear | 2 | ||
| 36 | 461-18-01011 | Differential cage | 1 | ||
| 37 | 461-18-01200 | Bolt | 1 | ||
| 38 | 461-18-01024 | Lock plate | 1 | ||
| 39 | GB6173 M27X2 | Nut M27X2 | 1 | ||
| 40 | NJ2307ENVX3 | Bearing | 1 | ||
| 41 | GB305 90/96.5 | Stop ring 90/96.5 | 1 | ||
| 42 | 461-18-01010 | Driving bevel gear | 1 | ||
| 43 | 01602-21442 | Washer 14 | 7 | ||
| 44 | 01050-51455 | Bolt M14X1.5X55 | 7 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 0 | 82310500 | Carrier assembly (front axle) | 1 | ||
| 0 | 82311600 | Carrier assembly (rear axle) |
|
1 |
68000-79000 руб. |
| 1 | 75201867 | Spur Pinion Set (front axle) 8×37LH | 1 | ||
| 1 | 75202362 | Spur Pinion Set (rear axle) 8×37RH | 1 | ||
| 2 | 75501992 | Nut M14×1.5 | 12 | ||
| 3 | 75500003 | Bolt M14×1.5×50 | 12 | ||
| 4 | 54500006 | Bearing 142807Y | 1 | ||
| 5 | 79605001 | Adjusting Shims | 1 | ||
| 6 | 54500003 | Bearing 47686/47620A | 2 | ||
| 7 | 75200118 | Adjusting Nut | 2 | ||
| 8 | 79600096 | Copper Copy | 1 | ||
| 9 | 79600095 | Bolt | 1 | ||
| 10 | 79600097 | Lock Shim | 1 | ||
| 11 | 51070004 | Nut M27×2 | 1 | ||
| 12 | 53500007 | Oil Seal HMSA780×100×10 | 1 | ||
| 13 | 53500008 | Oil Seal HMS480×100×10 | 1 | ||
| 14 | 50011008 | Bolt M12×1.5×55 | 1 | ||
| 15 | 50011011 | Bolt M14×1.5×55 | 7 | ||
| 16 | 75500269 | Lock Nut | 1 | ||
| 17 | 75500231 | Washer | 1 | ||
| 18 | 82310501 | Flange Assembly | 1 | ||
| 19 | 75201770 | Cover | 1 | ||
| 20 | 75201767 | Bearing Cage | 1 | ||
| 21 | 79605013 | Adjusting Shims | 1 | ||
| 22 | 79800027 | Carrier Housing | 1 | ||
| 23 | 54100015 | Bearing 31314 | 1 | ||
| 24 | 75200054 | Lock Shim | 2 | ||
| 25 | 50004003 | Bolt M10×20 | 2 | ||
| 26 | 79605010 | Bearing Spacers | 1 | ||
| 27 | 54100014 | Bearing 31313 | 1 | ||
| 28 | 52100012 | Snap Ring 90 | 1 | ||
| 29 | 82030502 | Differential Assembly |
|
1 |
30000-35000 руб. |
| 30 | 52020005 | Washer 14 | 7 | ||
| 31 | 52020004 | Washer 12 | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-07003 | Joint | 4 | ||
| 2 | ZL50G2-07004 | Joint | 1 | ||
| 3 | ZL50G2-07005 | Pipe clip | 3 | ||
| 4 | ZL50G2-07006B | Inlet pipe (for WEICHAI) | 1 | ||
| 4A | DG956WII-07006 | Inlet pipe | 1 | ||
| 5 | ZL50G3-07008A | Compressor outlet pipe (for WEICHAI) | 1 | ||
| 5A | DG956WII-07005 | Compressor outlet pipe (for SHANGHAI) | 1 | ||
| 5B | DG956WV-07005A | Compressor outlet pipe (for CUMMINS) | 1 | ||
| 6 | ZL50G2-07044 | Joint | 1 | ||
| 7 | ZL50G2-07043 | Joint | 1 | ||
| 8 | DG938-07008 | Link joint | 1 | ||
| 9 | DG938-07032 | Link bolt | 1 | ||
| 10 | ZL50G2-07015 | Link bolt | 2 | ||
| 11 | ZL50G2-07014C | Brake tube | 2 | ||
| 12 | ZL50G2-07013 | Link bolt | 2 | ||
| 13 | ZL50G2-07017C | Brake tube | 1 | ||
| 14 | ZL50G2-07009A | Air cylinder | 1 | ||
| 15 | ZL50G2-07022A | Air cylinder hoop | 2 | ||
| 16 | ZL50G2-07021A | Air cylinder bracket | 2 | ||
| 17 | ZL50G2-07027 | Tube | 1 | ||
| 18 | ZL50G2-07032 | ube | 1 | ||
| 19 | ZL50G2-07037 | Tube | 1 | ||
| 20 | ZL50G2-07011 | Boosting pump bracket | 1 | ||
| 21 | ZL50G2-07016A | Joint | 1 | ||
| (1) | XM60C-3514002 | Air brake valve | 1 | ||
| (2) | GB93-8 | Spring washer 8 | 4 | ||
| (3) | GB5781 M8×30 | Bolt M8×30 | 4 | ||
| (4) | XZ60A-3510010 | Air boosting pump | 1 | ||
| (4) | XM60-3510010 | Air boosting pump | 1 | ||
| (5) | GB 5781 M12×30 | Bolt M12×30 | 3 | ||
| (6) | GB 93 12 | Spring washer 12 | 5 | ||
| (7) | GB 6170 M12 | Nut M12 | 2 | ||
| (8) | GB93 6 | Spring washer 6 | 6 | ||
| (9) | GB5781 M6×40 | Bolt M6×40 | 6 | ||
| (10) | GB93-10 | Spring washer 10 | 12 | ||
| (11) | GB5781 M10×25 | Bolt M10×25 | 6 | ||
| (12) | JB982 14 | Combined washer 14 | 2 | ||
| (13) | SH380A-3511002 | Group valve | 1 | ||
| (14) | GB5781 M10×30 | Bolt M10V30 | 4 | ||
| (15) | GB6170 M10 | Nut M10 | 6 | ||
| (16) | GB5781 M10×70 | Bolt M10×70 | 2 | ||
| (17) | 35360070010 | Auto water drain valve |
|
1 | |
| (18) | JB982 22 | Combined washer 22 | 4 | ||
| (19) | JN150-372001 | Brake lamp switch | 1 | ||
| (20) | JB982 12 | Combined washer 12 | 8 | ||
| (21) | D2900-20000 | Clip 200×8 | 2 | ||
| (22) | GB5781 M12×25 | Bolt M12×25 | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-05008 | Radiator joint (for DG50B) | 2 | ||
| 1 | DG956A-12002 | Oil-in joint | 1 | ||
| 2 | ZL50G3-12004A | Steel pipe | 1 | ||
| 3 | ZL50G3-12005 | Joint | 1 | ||
| 4 | ZL50G3-12006 | Joint | 1 | ||
| 5 | ZL50G2-05008 | Joint | 3 | ||
| 6 | ZL50G3-12008 | Joint | 1 | ||
| 7 | ZL50G2-12021 | Big nut | 1 | ||
| 8 | ZL50G3-12010A | Steel pipe | 1 | ||
| 9 | DG956WI-12011 | Piezometer tube | 1 | ||
| 10 | ZL50G3-12012A | Tube Φ32×800 | 1 | ||
| 11 | ZL50G3-12013B | Steel pipe | 1 | ||
| 12 | ZL50G3-12014 | Tube Ф13×950 | 1 | ||
| 13 | ZL50G3-12015 | Joint | 1 | ||
| 14 | ZL50G3-12016A | Coning plug | 1 | ||
| 15 | ZL50G3-12017 | Joint | 1 | ||
| 16 | ZL50G3-12018 | Shoe plate | 1 | ||
| 17 | ZL50G3-12019 | Long joint | 1 | ||
| 18 | ZL50G2-12024 | Gasket | 1 | ||
| 19 | DG956WII-05008 | Oil-out joint | 1 | ||
| 20 | ZL50G2-12018 | Oil-in tube (for ZL60GT-1C) | 1 | ||
| (1) | DG50B | Oil radiator | 1 | ||
| (1) | ZL60GT-1C | Oil radiator | 1 | ||
| (1) | ZL60GT-AC | Oil radiator (for CUMMINS) | 1 | ||
| (2) | JH100 19I-2450 | Hose assembly 19I-2450 | 1 | ||
| (3) | JH100 19I-2100 | Hose assembly 19I-2100 | 1 | ||
| (4) | GB5783 M12×30 | Bolt M12×30 | 2 | ||
| (5) | GB93-12 | Spring washer 12 | 2 | ||
| (6) | GB5783 M8×35 | Bolt M8×35 | 4 | ||
| (7) | GB6170 M8 | Nut M8 | 4 | ||
| (8) | YL-163-00 | Oil filter | 1 | ||
| (9) | JH100 19I-830 | Hose assembly 19I-830 | 2 | ||
| (10) | JB3618.1 20～24 | Clamp 20～24 | 2 | ||
| (11) | GB3452.1 32.5×3.55 | O-ring 32.5×3.55 | 1 | ||
| (12) | GB93-10 | Spring washer 10 | 4 | ||
| (13) | GB5783 M10×25 | Bolt M10×25 | 4 | ||
| (14) | GB3618.1 43～48 | Clamp 43～48 | 2 | ||
| (15) | GB5783 M8×25 | Bolt M8×25 | 2 | ||
| (16) | GB93-8 | Spring washer 8 | 6 | ||
| (17) | JH100 25I-1508 | Hose assembly 25I-1508 | 1 | ||
| (18) | JB982 22 | Combined washer 22 | 1 | ||
| (19) | JB982 30 | Combined washer 30 | 5 | ||
| (20) | JB982 27 | Combined washer 27 | 2 | ||
| (21) | JH100 19I-2030 | Hose assembly 19I-2030 | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956WⅡ-12001 | Joint | 2 | ||
| 2 | DG956WⅡ-12002 | Joint | 2 | ||
| 3 | DG956WⅡ-12003A | Joint | 1 | ||
| 4 | DG956WI-12011 | Piezometer tube | 1 | ||
| (1) | JB982 30 | Combined washer 30 | 2 | ||
| (2) | JH100 22-2050 | Hose assembly 22-2050 | 1 | ||
| (3) | JH100 22-2500 | Hose assembly 22-2500 | 1 | ||
| (4) | JB982 27 | Combined washer 27 | 2 | ||
| (5) | JB982 10 | Combined washer 10 | 1 | ||
| (6) | JH100 22-2000 | Hose assembly (for CUMMINS) 22-2000 | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 0 | YL-163-00 | Filter assembly | 1 | ||
| 1 | YL-163-4 | Shell | 1 | ||
| 2 | YL-163-5 | Flange | 1 | ||
| 3 | YL-163-3 | Big and small nozzle (1 each) | 1 | ||
| 4 | YL-163-2 | O-ring 95×3.5 | 1 | ||
| 5 | YL-163-1 | Upper cover | 1 | ||
| 6 | YL-163-6 | Spring washer | 1 | ||
| 7 | YL-163-100 | Filter core module | 1 | ||
| 8 | YL-163-8 | O-ring 95×3.1 | 1 | ||
| 9 | YL-163-21 | Combined washer 16 | 1 | ||
| 10 | YL-163-22 | Bolt M16×1.5 | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-05001 | Right steering cylinder front joint | 1 |
22000-26000 руб. |
|
| 2 | ZL50G2-05002 | Right steering cylinder rear joint | 1 | ||
| 3 | ZL50G2-05003 | Hollow bolt | 3 | ||
| 4 | ZL50G2-05004 | Rear frame joint | 1 | ||
| 5 | ZL50G2-05010 | Left steering cylinder rear joint | 1 | ||
| 6 | ZL50G2-05011 | Left steering cylinder front joint | 1 | ||
| 7 | ZL50G2-05012 | Hollow bolt | 1 | ||
| 8 | ZL50G2-05019A | Hose assembly 19-970 | 1 | ||
| 9 | ZL50G2-05020 | Hose assembly 19-1130 | 2 | ||
| 10 | ZL50G2-05027A | Hose assembly 19-710 | 1 | ||
| (1) | DG958-05200 | Steering cylinder |
|
1 |
27000-31000 руб. |
| (2) | JH100 19-660 | Hose assembly 19-660 | 2 | ||
| (3) | GB93-12 | Spring washer 12 | 2 | ||
| (4) | GB5783 M12x25 | Bolt M12x25 | 2 | ||
| (5) | M1H-12 | Split flange M8 | 4 | ||
| (6) | GB5783 M10×30 | Bolt M10×30 | 4 | ||
| (7) | GB6170 M10 | Nut M10 | 4 | ||
| (8) | GB93-10 | Spring washer 10 | 4 | ||
| (9) | GB3452.1 25×3.55 | O-ring 25×3.55 | 4 | ||
| (10) | GB5783 M8×30 | Bolt M8×30 | 16 | ||
| (11) | GB93-8 | Spring washer 8 | 16 | ||
| (12) | GB3452.1 23.6×3.55 | O-ring 23.6×3.55 | 8 | ||
| (13) | JB982 14 | Combined washer 14 | 1 | ||
| (14) | JB1000 M14×1.5 | Plug M14×1.5 | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-05029 | Tube clip | 4 | ||
| 2 | ZL50G2-05013 | Oil in/out joint, steering device | 2 | ||
| 3 | ZL50G2-05014 | To steering cylinder joint | 2 | ||
| 4 | ZL50G2-05015 | Hollow bolt | 4 | ||
| 5 | ZL50G2-05016 | Hollow bolt | 1 | ||
| 6 | ZL50G2-05021 | Hose assembly 19-1515 | 1 | ||
| 7 | ZL50G2-05022 | Hose assembly 19-1495 | 1 | ||
| (1) | GB93-10 | Spring washer 10 | 2 | ||
| (2) | GB6170 M10 | Nut M10 | 2 | ||
| (3) | GB5783 M10×40 | Bolt M10×40 | 2 | ||
| (4) | JB982 20 | Combined washer 20 | 8 | ||
| (5) | JB982 12 | Combined washer 12 | 2 | ||
| (6) | BZZ-1000 | Steering device assembly |
|
1 |
27000-32000 руб. |
| (7) | FK-/21 | Combined valve block | 2 | ||
| (8) | JH100 19Ⅰ-1250 | Hose assembly 19Ⅰ-1250 | 1 | ||
| (9) | JH100 19Ⅰ-3330 | Hose assembly (for SL50W-3) 19Ⅰ-3330 | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956-05001 | Oil return tube, unloading valve | 1 | ||
| 2 | DG956-05002 | Confluence tube, unloading valve to oil way board | 1 | ||
| 3 | DG956-05003 | Oil tube, steering pump to unloading valve | 1 | ||
| 4 | DG956-05004 | Oil tube, deflector to unloading valve | 1 | ||
| 5 | DG956-05005 | Reaction oil tube, deflector to unloading valve | 1 | ||
| 6 | DG956-05007 | Joint | 1 | ||
| 7 | ZL50G3-05017 | Hose φ45×810 | 1 | ||
| 8 | ZL50G3-05018 | Steering pump oil-in steel tube | 1 | ||
| (1) | JHP2100 | Gear pump P |
|
1 |
30000-35000 руб. |
| (2) | GB 898 M12x35 | Double-screw bolt A M12x35 | 4 | ||
| (3) | GB6170 M12 | Nut M12 | 4 | ||
| (4) | GB93-12 | Spring washer 12 | 8 | ||
| (5) | LFS1 1/4 /28LA | Flange joint | 1 | ||
| (6) | 51H-20 | Split flange | 3 | ||
| (7) | GB3452.1 37.5×3.55 | O-ring 37.5×3.55 | 2 | ||
| (8) | GB5783 M12x30 | Bolt M12x30 | 4 | ||
| (9) | GB3618.1 57~62 | Clamp 57~62 | 4 | ||
| (10) | GB3452.1 43.7×3.55 | O-ring 43.7×3.55 | 1 | ||
| (11) | GB5783 M8×30 | Bolt M8×30 | 1 | ||
| (12) | GB93-8 | Spring washer 8 | 1 | ||
| (13) | M1H-12 | Split flange M10 | 1 | ||
| (14) | GB3452.1 25×3.55 | O-ring 25×3.55 | 1 | ||
| (15) | M1H-16 | Split flange | 2 | ||
| (16) | GB3452.1 32.5×3.55 | O-ring 32.5×3.55 | 2 | ||
| (17) | GB5783 M10x30 | Bolt M10x30 | 17 | ||
| (18) | GB93-10 | Spring washer 10 | 28 | ||
| (19) | LFS1/28L | Flange joint | 1 | ||
| (20) | GB70 M10×30 | Screw M10×30 | 8 | ||
| (21) | YXH25 | Priority unloading valve |
|
1 |
25000-29000 руб. |
| (22) | GB5783 M10×75 | Bolt M10×75 | 3 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-05005 | Reaction oil tube joint | 2 | ||
| 2 | ZL50G2-05006 | Priority valve joint | 1 | ||
| 3 | ZL50G3-05017 | Hose φ45×810 | 1 | ||
| 4 | ZL50G3-05018 | Steering pump oil-in steel tube | 1 | ||
| 5 | ZL50G3-05023 | Confluence tube, priority valve to oil way board | 1 | ||
| 6 | ZL50FIII-05024A | Oil tube, steering pump to priority valve | 1 | ||
| 7 | ZL50G3-05025 | Hose assembly 8I-700 | 1 | ||
| 8 | ZL50G3-05026 | Reaction oil tube, deflector to priority valve | 1 | ||
| (1) | GB3618.1 57~62 | Clamp 57~62 | 4 | ||
| (2) | JH100 19-2200 | Hose assembly 19-2200 | 1 | ||
| (3) | VLE-150 | Priority valve | 1 | ||
| (4) | GB70 M10x90 | Screw M10x90 | 2 | ||
| (5) | GB93-10 | Spring washer 10 | 18 | ||
| (6) | GB95 10 | Flat washer 10 | 2 | ||
| (7) | GB3452.1 43.7×3.55 | O-ring 43.7 x 3.55 | 1 | ||
| (8) | GB5783 M10x30 | Bolt M10x30 | 12 | ||
| (9) | 51H-20 | Split flange | 1 | ||
| (10) | GB3452.1 37.5×3.55 | O-ring 37.5 x 3.55 | 4 | ||
| (11) | GB70 M10×30 | Screw M10 x 30 | 4 | ||
| (12) | LFS 1 1/4′28LA | Flange joint | 1 | ||
| (13) | JHP2100 | Gear pump P |
|
1 |
30000-35000 руб. |
| (14) | GB 898 M12x35 | Double-screw bolt A M12x35 | 4 | ||
| (15) | GB6170 M12 | Nut M12 | 4 | ||
| (16) | GB5783 M12x30 | Bolt M12x30 | 4 | ||
| (17) | GB95-12 | Washer 12 | 4 | ||
| (18) | GB93-12 | Spring washer 12 | 8 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G3-05023 | Oil tube, steering pump to priority valve | 1 | ||
| 2 | DG956WⅡ-05026 | Hose assembly 8Ι-700 | 1 | ||
| 3 | ZL50G3-05026 | Reaction oil tube, deflector to priority valve | 1 | ||
| 4 | ZL50G2-05005 | Reaction oil tube joint | 2 | ||
| 5 | DG956WⅡ-05025 | Oil tube, steering pump to priority valve | 1 | ||
| 6 | ZL50G2-05006 | Priority valve joint | 1 | ||
| 7 | DG956WⅡ-05007 | Hose 32×2600 | 1 | ||
| 8 | DG956WⅡ-05018 | Hose 45×680 | 1 | ||
| 9 | DG956WⅡ-05008 | Radiator oil-in joint | 1 | ||
| 10 | DG956WⅡ-05019 | Steering pump oil-in steel tube | 1 | ||
| 11 | DG956WⅡ-05030 | Right-angle joint | 1 | ||
| 12 | DG956WⅡ-05009 | Radiator oil-out joint | 1 | ||
| 13 | DG956WⅡ-05031 | Steering pump oil-out steel tube | 1 | ||
| (1) | JB3618.1 57~62 | Clamp 57~62 | 4 | ||
| (2) | JB1000 14×1.5 | Plug screw M14×1.5 | 1 | ||
| (3) | JB982 14 | Combined washer 14 | 1 | ||
| (4) | JH100 19-2250 | Hose assembly 19-2250 | 1 | ||
| (5) | VLE-150 | Priority valve | 1 | ||
| (6) | GB70 M10x90 | Screw M10x90 | 2 | ||
| (7) | GB93-10 | Spring washer 10 | 34 | ||
| (8) | GB95 10 | Washer 10 | 2 | ||
| (9) | JB982 30 | Combined washer 30 | 2 | ||
| (10) | JH100 19Ⅰ-3330 | Hose assembly 19Ⅰ-3330 | 1 | ||
| (11) | GB3452.1 43.7×3.55 | O-ring 43.7×3.55 | 1 | ||
| (12) | GB5783 M12x30 | Bolt M12x30 | 4 | ||
| (13) | 51H-20 | Flange | 6 | ||
| (14) | GB3452.1 37.5×3.55 | O-ring 37.5×3.55 | 6 | ||
| (15) | JHP3100 | Gear pump |
|
1 |
78000-91000 руб. |
| (16) | GB5783 M10x35 | Bolt M10x35 | 32 | ||
| (17) | GB 898 M12x50 | Double-screw bolt A M12x50 | 4 | ||
| (18) | GB6170 M12 | Nut M12 | 4 | ||
| (19) | GB93-12 | Spring washer 12 | 8 | ||
| (20) | JB3618.1 43~48 | Clamp 43~48 | 4 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-06001A | Lever protector | 1 | ||
| 2 | ZL50G2-06002 | Small cavity nozzle | 1 | ||
| 3 | ZL50G2-06003 | Oil tube | 2 | ||
| 4 | ZL50G2-06004 | Big cavity nozzle | 1 | ||
| 5 | ZL50G2-06005A | Mid-joint | 2 | ||
| 6 | ZL50FIII-06016 | Oil-in tube II | 1 | ||
| 6A | ZL50G2-06033 | Mid-pipe Ⅰ, work valve | 1 | ||
| 7 | ZL50FIII-06018 | Oil-in tube I | 1 | ||
| 7A | ZL50G2-06028 | Mid-pipe II, work valve | 1 | ||
| (1) | GB5783 M12×25 | Bolt M12×25 | 6 | ||
| (2) | GB93-10 | Spring washer 10 | 40 | ||
| (3) | GB5783 M10×65 | Bolt M10×65 | 8 | ||
| (4) | DG958-06500 | Tipping cylinder | 1 | ||
| (4) | DG956-06500A | Tipping cylinder (for long arm) | 1 | ||
| (5) | GB3452.2 32.5×3.55 | O-ring 32.5×3.55 | 2 | ||
| (6) | GB5783 M10×35 | Bolt M10×35 | 32 | ||
| (7) | 51H-20 | Flange | 8 | ||
| (8) | GB3452.2 37.5×3.55 | O-ring 37.5×3.55 | 8 | ||
| (9) | GB93-12 | Spring washer 12 | 6 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50FIII-06017 | Return nozzle II, work valve | 1 | ||
| 2 | ZL50FIII-06100A | Control system | 1 | ||
| 3 | ZL50FIII-06019 | Return joint, work valve | 1 | ||
| 4 | ZL50G2-06054 | Tube clip | 4 | ||
| 5 | ZL50G2-06048B | Joint, lifting cylinder big cavity (L) | 1 | ||
| 6 | ZL50G2-06049B | Joint, lifting cylinder big cavity (R) |
|
1 |
3200-3700 руб. |
| 7 | ZL50G2-06045 | Joint, lifting cylinder small cavity (L) | 1 | ||
| 8 | ZL50G2-06046 | Joint, lifting cylinder small cavity (R) | 1 | ||
| 9 | ZL50FIII-06020 | Joint, work valve small cavity | 1 | ||
| 10 | ZL50FIII-06021 | Joint, work valve big cavity | 1 | ||
| 11 | ZL50G2-06041 | Tube, lifting cylinder big cavity | 2 | ||
| 12 | ZL50G2-06042 | Tube, lifting cylinder small cavity | 2 | ||
| 13 | ZL50FIII-06015 | Oil-in tube, work valve I | 1 | ||
| 14 | ZL50G2-06050A | Tube clip | 2 | ||
| 15 | ZL50FⅢ-06042 | Connect board | 2 | ||
| 16 | ZL50G2-06047B | Tube clip | 4 | ||
| (1) | GB5783 M12×35 | Bolt M12×35 | 8 | ||
| (2) | GB93-12 | Spring washer 12 | 12 | ||
| (3) | GB3452.2 47.5×3.55 | O-ring 47.5×3.55 | 2 | ||
| (4) | 51H-24 | Flange | 2 | ||
| (5) | GB5783 M10×65 | Bolt M10×65 | 16 | ||
| (6) | GB1235 50×3.1 | O-ring 50×3.1 | 1 | ||
| (7) | GB5780 M10×55 | Bolt M10×55 | 2 | ||
| (8) | GB6170 M10 | Nut M10 | 8 | ||
| (9) | DG958-06600 | Lifting cylinder | 2 | ||
| (9) | DG958-J06600 | Lifting cylinder (for extend arm and long arm) | 2 | ||
| (10) | GB3452.2 32.5×3.55 | O-ring 32.5×3.55 | 4 | ||
| (11) | GB6170 M12 | Nut M12 | 4 | ||
| (12) | GB5780 M12×120 | Bolt M12×120 | 2 | ||
| (13) | GB5783 M10×35 | Bolt M10×35 | 60 | ||
| (14) | GB93-10 | Spring washer 10 | 81 | ||
| (15) | GB95 10 | Washer 10 | 6 | ||
| (16) | GB5783 M10×40 | Bolt M10×40 | 2 | ||
| (17) | DF32.2C | Multiple unit valve | 1 | ||
| (18) | GB3452.2 37.5×3.55 | O-ring 37.5×3.55 | 14 | ||
| (19) | 51H-20 | Flange | 14 | ||
| (20) | GB5780 M12×135 | Bolt M12×135 | 2 | ||
| (21) | GB5783 M10×30 | Bolt M10×30 | 1 | ||
| (22) | GB93-8 | Spring washer 8 | 2 | ||
| (23) | GB6170 M8 | Nut M8 | 2 | ||
| (24) | GB5781 M8×25 | Bolt M8×25 | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-06046 | Joint, lifting cylinder small cavity (R) | 1 | ||
| 2 | ZL50G2-06045 | Joint, lifting cylinder small cavity (L) | 1 | ||
| 3 | ZL50G2-06049B | Joint, lifting cylinder large cavity (R) |
|
1 |
3200-3700 руб. |
| 4 | ZL50G2-06048B | Joint, lifting cylinder large cavity (L) | 1 | ||
| 5 | ZL50G2-06054 | Tube clip | 4 | ||
| 6 | ZL50G2-06030 | Return nozzle II, work valve | 1 | ||
| 7 | ZL50G2-06027B | Tube clip | 1 | ||
| 8 | ZL50G2-06031 | Lead screw | 3 | ||
| 9 | ZL50G2-06047B | Tube clip | 4 | ||
| 10 | ZL50G2-06032 | Oil return joint, work valve | 1 | ||
| 11 | ZL50G2-06034 | Joint, work valve large cavity | 1 | ||
| 12 | ZL50G2-06035 | Joint, work valve small cavity | 1 | ||
| 13 | ZL50G2-06029 | Oil-in tube, work valve I | 1 | ||
| 14 | ZL50G2-06041 | Tube, lifting cylinder large cavity | 2 | ||
| 15 | ZL50G2-06042 | Tube, lifting cylinder small cavity | 2 | ||
| 16 | ZL50G2-06024B | Tube clip Ⅰ | 1 | ||
| 17 | ZL50FⅢ-06042 | Connect board | 2 | ||
| 18 | ZL50G2-06050A | Tube clip | 2 | ||
| (1) | GB5783 M10×65 | Bolt M10×65 | 16 | ||
| (2) | GB3452.2 32.5×3.55 | O-ring 32.5×3.55 | 4 | ||
| (3) | DG958-06600 | Lifting cylinder | 2 | ||
| (3) | DG958-J06600 | Lifting cylinder (for extend arm and long arm) | 2 | ||
| (4) | GB6170 M10 | Nut M10 | 8 | ||
| (5) | GB5783 M12×35 | Bolt M12×35 | 8 | ||
| (6) | GB898 M12×40 | Double-screw Bolt M12×40 | 4 | ||
| (7) | GB5781 M8×25 | Bolt M8×25 | 2 | ||
| (8) | GB6170 M8 | Nut M8 | 2 | ||
| (9) | GB93-8 | Spring washer 8 | 2 | ||
| (10) | GB3452.2 43.7×3.55 | O-ring 43.7×3.55 | 1 | ||
| (11) | GB5783 M10×30 | Bolt M10×30 | 8 | ||
| (12) | GB95 10 | Washer 10 | 6 | ||
| (13) | D32.2 | Hydraulic control multiple unit valve | 1 | ||
| (13) | YDF32.2 | Hydraulic control multiple unit valve | 1 | ||
| (14) | 51H-24 | Flange | 3 | ||
| (15) | GB3452.2 47.5×3.55 | O-ring 47.5×3.55 | 3 | ||
| (16) | GB5783 M12×30 | Bolt M12×30 | 8 | ||
| (17) | GB93-12 | Spring washer 12 | 12 | ||
| (18) | GB5783 M10×35 | Bolt M10×35 | 48 | ||
| (19) | GB93-10 | Spring washer 10 | 78 | ||
| (20) | GB3452.2 37.5×3.55 | O-ring 37.5×3.55 | 13 | ||
| (21) | 51H-20 | Flange | 13 | ||
| (22) | GB5780 M10×55 | Bolt M10×55 | 4 | ||
| (23) | GB5783 M10×40 | Bolt M10×40 | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-05009 | Radiator oil-out joint | 1 | ||
| 2 | ZL50FIII-06008A | Oil suction joint assembly | 1 | ||
| 3 | ZL50FIII-06009C | Oil return joint assembly | 1 | ||
| 4 | ZL50G3-06020 | Hose | 1 | ||
| 5 | ZL50G3-06021A | Oil-out tube, work pump | 1 | ||
| 6 | ZL50G2-06024B | Tube clip I | 1 | ||
| 7 | ZL50G2-06025A | Oil-in tube, work valve II | 1 | ||
| 8 | ZL50G2-06026C | Oil return tube, work valve I | 1 | ||
| 9 | ZL50FIII-06035 | Hose φ32×590 | 1 | ||
| 10 | ZL50FIII-06036 | Hose φ32×2420 | 1 | ||
| 11 | ZL50FIII-06037 | Radiator oil-in joint | 1 | ||
| 12 | ZL50FIII-06037A | Radiator oil-in joint (for ZL60GT-1C) | 1 | ||
| 13 | ZL50FIII-06038A | Radiator oil-out joint (for ZL60GT-1C) | 1 | ||
| 14 | ZL50FIII-06039 | Bracket | 1 | ||
| 15 | ZL50G2-06039 | Fixed plate | 1 | ||
| 16 | ZL50FIII-06040 | Oil-way board | 1 | ||
| 17 | ZL50FIII-06041 | Metal tube assembly | 1 | ||
| 18 | ZL50G3-06046 | Oil suction joint, work pump | 1 | ||
| 19 | ZL50G2-06052B | Tube clip II | 1 | ||
| 20 | ZL50G2-06053 | Rubber mat | 1 | ||
| 21 | DG956W-06200 | Engine oil tank assembly | 1 | ||
| (1) | LFS1 1/4′28LA | Flange joint | 2 | ||
| (2) | GB5783 M12×35 | Bolt M12×35 | 4 | ||
| (3) | 51H-24 | Flange | 1 | ||
| (4) | GB3452.2 47.5×3.55 | O-ring 47.5×3.55 | 1 | ||
| (5) | CBGj3100A | Gear pump |
|
1 |
41000-48000 руб. |
| (6) | JB1000 M14×1.5 | Plug screw M14×1.5 | 1 | ||
| (7) | JB982 14 | Combined washer 14 | 1 | ||
| (8) | GB93-12 | Spring washer 12 | 14 | ||
| (9) | GB5783 M12×25 | Bolt M12×25 | 2 | ||
| (10) | GB5781 M10×20 | Bolt M10×20 | 3 | ||
| (11) | GB6170 M12 | Nut M12 | 8 | ||
| (12) | GB898 A M12×35 | Double-screw bolt A M12×35 | 4 | ||
| (13) | GB3452.2 37.5×3.55 | O-ring 37.5×3.55 | 6 | ||
| (14) | 51H-20 | Flange | 6 | ||
| (15) | GB3618.1 57～62 | Clamp 57～62 | 4 | ||
| (16) | GB1235 65×3.1 | O-ring 65×3.1 | 2 | ||
| (17) | GB5783 M10×30 | Bolt M10×30 | 24 | ||
| (18) | JH100 25I-1190 | Hose assembly 25I-1190 | 1 | ||
| (19) | GB93-10 | Spring washer 10 | 32 | ||
| (20) | GB5780 M10×55 | Bolt M10×55 | 4 | ||
| (21) | GB93-10 | Spring washer 10 | 12 | ||
| (22) | GB5781 M8×20 | Bolt M8×20 | 12 | ||
| (23) | JH100 25I-2250 | Hose assembly 25I-2250 | 1 | ||
| (24) | JB982 30 | Combined washer 30 | 2 | ||
| (25) | JB982 27 | Combined washer 27 | 2 | ||
| (26) | GB5781 M10×40 | Bolt M10×40 | 1 | ||
| (27) | GB97.1 10 | Washer 10 | 2 | ||
| (28) | GB3618.1 43～48 | Clamp 43～48 | 8 | ||
| (29) | GB3452.2 43.7×3.55 | O-ring 43.7×3.55 | 1 | ||
| (30) | GB5783 M12×30 | Bolt M12×30 | 4 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-06026C | Oil return tube I, work valve Ⅰ | 1 | ||
| 2 | ZL50G3-06020 | Hose | 1 | ||
| 3 | ZL50G2-06025 | Oil-in tube I, work valve Ⅱ | 1 | ||
| 4 | ZL50FⅢ-06008A | Suction joint assembly | 1 | ||
| 5 | ZL50G3-06021A | Oil-out tube, work valve | 1 | ||
| 6 | ZL50G2-06053 | Rubber mat | 1 | ||
| 7 | ZL50G2-06052B | Tube clip Ⅱ | 1 | ||
| 8 | ZL50G2-06023B | Oil return joint assembly | 1 | ||
| 9 | ZL50FⅢ-06037 | Radiator oil-in joint | 1 | ||
| 10 | ZL50FⅢ-06037A | Radiator oil-in joint (for ZL60GT-1C) | 1 | ||
| 11 | ZL50G3-06046 | Suction joint, work pump | 1 | ||
| 12 | ZL50FⅢ-06036 | Hose | 1 | ||
| 13 | ZL50G2-05009 | Radiator oil-out joint | 1 | ||
| 14 | ZL50FⅢ-06038A | Radiator oil-out joint (for ZL60GT-1C) | 1 | ||
| 15 | ZL50G2-06039 | Fixed plate | 1 | ||
| 16 | ZL50G2-06040 | Oil board | 1 | ||
| 17 | ZL50FⅢ-06035 | Hose | 1 | ||
| 18 | ZL50FⅢ-06039 | Bracket | 1 | ||
| (1) | 51H-24 | Flange | 1 | ||
| (2) | GB3452.2 47.5×3.55 | O-ring 47.5×3.55 | 1 | ||
| (3) | GB5783 M12×35 | Bolt M12×35 | 4 | ||
| (4) | JB3618.1 57~62 | Clamp 57~62 | 4 | ||
| (5) | CBGj3100/1010-XF | Gear pump | 1 | ||
| (6) | GB3452.2 37.5×3.55 | O-ring 37.5×3.55 | 3 | ||
| (7) | 51H-20 | Flange | 3 | ||
| (8) | GB5783 M10×30 | Bolt M10×30 | 12 | ||
| (9) | GB1235 65×3.1 | O-ring 65×3.1 | 2 | ||
| (10) | GB5780 M10×55 | Bolt M10×55 | 2 | ||
| (11) | GB5781 M8×20 | Bolt M8×20 | 12 | ||
| (12) | GB93-8 | Spring washer 8 | 12 | ||
| (13) | JH100 25I-2450 | Hose assembly 25I-2450 | 1 | ||
| (14) | JB982 30 | Combined washer 30 | 2 | ||
| (15) | JB982 27 | Combined washer 27 | 2 | ||
| (16) | GB3452.2 43.7×3.55 | O-ring 43.7×3.55 | 1 | ||
| (17) | GB5783 M12×30 | Bolt M12×30 | 4 | ||
| (18) | JB3618.1 43~48 | Clamp 43~48 | 8 | ||
| (19) | GB5781 M10×40 | Bolt M10×40 | 1 | ||
| (20) | GB97.1 10 | Washer 10 | 2 | ||
| (21) | GB93-10 | Spring washer 10 | 48 | ||
| (22) | GB93-12 | Spring washer 12 | 10 | ||
| (23) | GB5781 M12×25 | Bolt M12×25 | 2 | ||
| (24) | JB1000 M14×1.5 | Plug screw M14×1.5 | 1 | ||
| (25) | JB982 14 | Combined washer 14 | 1 | ||
| (26) | GB5781 M10×20 | Bolt M10×20 | 3 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956WⅡ-05018 | Hose | 1 | ||
| 2 | DG956WⅡ-06007 | Oil–out tube, work pump | 1 | ||
| 3 | DG956WⅡ-06008 | Suction joint assembly | 1 | ||
| 4 | DG956WⅡ-06009 | Oil return joint assembly | 1 | ||
| 5 | DG956W-06200 | Engine oil tank | 1 | ||
| 6 | ZL50G2-06052B | Tube clip Ⅱ | 1 | ||
| 7 | ZL50G2-06053 | Rubber mat | 1 | ||
| 8 | ZL50G2-06025 | Oil-in tube Ⅱ, work valve | 1 | ||
| 9 | ZL50G2-06026C | Oil return tube Ⅰ, work valve | 1 | ||
| 10 | ZL50G2-06027B | Tube clip | 1 | ||
| 11 | ZL50G2-06039 | Fixed plate | 1 | ||
| 12 | ZL50G2-06040 | Oil board | 1 | ||
| 13 | DG956WⅡ-06027 | Suction joint, work pump | 1 | ||
| 14 | ZL50G2-06024B | Tube clip Ⅰ | 1 | ||
| (1) | GB93-12 | Spring washer 12 | 14 | ||
| (2) | GB3452.2 47.5×3.55 | O-ring 47.5×3.55 | 1 | ||
| (3) | GB5783 M12×30 | Bolt M12×30 | 4 | ||
| (4) | 51H-24 | Flange | 1 | ||
| (5) | JHP3100C | Gear pump | 1 | ||
| (6) | GB898 M12×65 | Double-screw bolt M12×65 | 4 | ||
| (7) | GB6170 M12 | Nut M12 | 4 | ||
| (8) | JB3618.1 57~62 | Clamp 57~62 | 4 | ||
| (9) | GB3452.2 37.5×3.55 | O-ring 37.5×3.55 | 3 | ||
| (10) | 51H-20 | Flange | 3 | ||
| (11) | GB1235 65×3.1 | O-ring 65×3.1 | 2 | ||
| (12) | GB5783 M10×30 | Bolt M10×30 | 12 | ||
| (13) | GB97 10 | Spring washer 10 | 20 | ||
| (14) | GB93-8 | Spring washer 8 | 12 | ||
| (15) | GB5781 M8×20 | Bolt M8×20 | 12 | ||
| (16) | GB5780 M10×55 | Bolt M10×55 | 6 | ||
| (17) | GB5781 M12×25 | Bolt M12×25 | 2 | ||
| (18) | JB982 14 | Combined washer 14 | 1 | ||
| (19) | JB1000 M14×1.5 | Plug M14×1.5 | 1 | ||
| (20) | GB5781 M10×20 | Bolt M10×20 | 2 | ||
| (21) | GB5783 M12×30 | Bolt M12×30 | 4 | ||
| (22) | GB3452.2 43.7×3.55 | O-ring 43.7×3.55 | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-06024B | Tube clipⅠ Ⅰ | 1 | ||
| 2 | ZL50G2-06027B | Tube clip | 1 | ||
| 3 | ZL50G2-06026C | Oil return tubeⅠ, work valve Ⅰ | 1 | ||
| 4 | ZL50G2-06025 | Oil-in tubeⅡ, work valve Ⅱ | 1 | ||
| 5 | DG956WⅢ-06046 | Suction joint, work pump | 1 | ||
| 6 | DG956WⅢ-06020A | Hose | 1 | ||
| 7 | DG956WⅡ-06007 | Oil-out tube, work pump | 1 | ||
| 8 | DG956WⅡ-06008 | Suction joint assembly | 1 | ||
| 9 | ZL50G2-06022A | Oil return joint assembly | 1 | ||
| 10 | DG956W-06200 | Engine oil tank | 1 | ||
| 11 | ZL50G2-06040 | Oil board | 1 | ||
| 12 | ZL50G2-06039 | Fixed board | 1 | ||
| 13 | ZL50G2-06053 | Rubber mat | 1 | ||
| 14 | ZL50G2-06052 | Tube clipⅡ Ⅱ | 1 | ||
| 15 | DG956WⅢ-06054 | Oil-out tube, work pump | 1 | ||
| (1) | CBGj3100/1010C-XF | Gear pump | 1 | ||
| (2) | GB898 M12×65 | Double-screw bolt M12×65 | 4 | ||
| (3) | GB 6170 M12 | Nut M12 | 4 | ||
| (4) | GB 95 12 | Washer 12 | 4 | ||
| (5) | GB3452.2 43.7×3.55 | O-ring 43.7×3.55 | 1 | ||
| (6) | GB5783 M12×30 | Bolt M12×30 | 4 | ||
| (7) | JB3618.1 57~62 | Clamp 57~62 | 4 | ||
| (8) | GB1235 65×3.1 | O-ring 65×3.1 | 2 | ||
| (9) | GB5783 M10×30 | Bolt M10×30 | 8 | ||
| (10) | GB5781 M8×20 | Bolt M8×20 | 12 | ||
| (11) | GB93-8 | Spring washer 8 | 12 | ||
| (12) | GB93-12 | Spring washer 12 | 14 | ||
| (13) | 51H-24 | Flange | 1 | ||
| (14) | GB3452.2 47.5×3.55 | O-ring 47.5×3.55 | 1 | ||
| (15) | B5783 M12×35 | Bolt M12×35 | 4 | ||
| (16) | GB5781 M10×20 | Bolt M10×20 | 2 | ||
| (17) | JB982 14 | Combined washer 14 | 1 | ||
| (18) | JB1000 M14×1.5 | Plug M14×1.5 | 1 | ||
| (19) | GB5781 M12×25 | Bolt M12×25 | 2 | ||
| (20) | GB97 10 | Spring washer 10 | 24 | ||
| (21) | GB5783 M10×35 | Bolt M10×35 | 8 | ||
| (22) | 51H-20 | Bolt | 4 | ||
| (23) | GB3452.2 37.5×3.55 | O-ring 37.5×3.55 | 4 | ||
| (24) | GB5780 M10×55 | Bolt M10×55 | 6 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 0 | DG956W-06200 | Engine tank assembly | 1 | ||
| 1 | DG956W-06201 | Engine oil tank | 1 | ||
| 2 | ZL50G2-06202B | Screen assembly 1 | 1 | ||
| 3 | ZL50G2-06204D | Flange | 1 | ||
| 4 | ZL50G2-06206B | Rubber pad | 1 | ||
| 5 | YLX-53 | Oil suction filter | 1 | ||
| 6 | YLX-50 | Return filter | 1 | ||
| 7 | ZL50G2-01207 | Baffle | 1 | ||
| 8 | ZL50G2-06211B | Screen assembly 2 | 1 | ||
| 9 | ZL30GII-01203 | Magnet | 1 | ||
| (1) | GB93-8 | Spring washer 8 | 22 | ||
| (2) | GB5783 M8×20 | Bolt M8×20 | 22 | ||
| (3) | QL-10-00 | Oil filling filter | 1 | ||
| (4) | GB5783 M20×40 | Bolt M20×40 | 4 | ||
| (5) | GB93-20 | Spring washer 20 | 4 | ||
| (6) | GB5787 M8×25 | Bolt M8×25 | 2 | ||
| (8) | GB3452.1 136×3.55 | O-ring 136×3.55 | 2 | ||
| (9) | GB95-20 | Flat washer 20 | 4 | ||
| (10) | YWZ-127 | Level indicator | 1 | ||
| (11) | JB982 27 | Combined washer 27 | 1 | ||
| (12) | JB1000 M27×2 | Plug screw M27×2 | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50G2-01002 | Water tank pad | 2 | ||
| 1A | DG956WⅡ-01001 | Water tank pad (forZL60GT-1C) | 2 | ||
| 2 | ZL50G3-01002 | Engine inlet pipe | 1 | ||
| 2A | DG958-01003B | Engine inlet pipe (for ZL60GT-1C) | 1 | ||
| 3 | ZL50G2-01004 | Engine shock pad | 2 | ||
| 4 | ZL50G2-01005B | Engine front bracket | 2 | ||
| 5 | ZL50G2-01006 | Tube pipe | 1 | ||
| 6 | DG956WI-01006 | Manometry hose | 1 | ||
| 7 | ZL50G2-01007 | Link bolt | 3 | ||
| 8 | ZL50G2-01013 | Bolt | 8 | ||
| 9 | ZL50G3-01009A | Engine left-front bracket | 1 | ||
| 10 | ZL50G2-01009 | Throttle flexible shaft 3000mm |
|
1 |
2500-2900 руб. |
| 11 | DG957-01200 | Fuel tank assembly | 1 | ||
| 14 | ZL50G3-01013 | Throttle bracket | 1 | ||
| 17 | ZL50G2-01015 | Engine outlet pipe φ45×650 |
|
1 |
5000-6000 руб. |
| 17A | DG958-01015B | Engine outlet pipe (for ZL60GT-1C) | 1 | ||
| 18 | ZL50G3-01017A | Engine right-rear bracket | 1 | ||
| 19 | ZL50G3-01018 | Connection hose | 1 | ||
| 21 | ZL50G2-01023 | Washer | 4 | ||
| 22 | ZL50G2-01024 | Engine shock pad | 4 | ||
| 23 | ZL50G2-01025 | Support sleeve | 8 | ||
| 24 | ZL50G3-01025 | Washer | 4 | ||
| 25 | DG958-01030 | Baffle (for ZL60GT-1C) | 1 | ||
| 26 | ZL50G3-01027 | Engine shock pad | 2 | ||
| (1) | JB3618.1 55～60 | Clamp 55～60 | 4 | ||
| (2) | GB5782 M14×70 | Bolt M14×70 | 4 | ||
| (3) | GB95-14 | Flat washer 14 | 4 | ||
| (4) | GB889 M14 | Nut M14 | 4 | ||
| (5) | GB3452 10A-A-2100 | Oil transfer hose 10A-A-2100 | 1 | ||
| (5) | GB3452 10A-A-2600 | Oil transfer hose 10A-A-2600 (WD10G220E21) | 1 | ||
| (6) | JB982 14 | Combined washer 14 | 6 | ||
| (9) | GB3452 10A-A-2100 | Oil transfer hose 10A-A-2100 | 1 | ||
| (9) | GB3452 10A-A-2200 | Oil transfer hose 10A-A-2200 (WD10G220E21) | 1 | ||
| (10) | GB93-14 | Spring washer 14 | 8 | ||
| (14) | GB5781 M6×16 | Bolt M6×16 | 5 | ||
| (15) | GB93 6 | Spring washer 6 | 5 | ||
| (16) | XZ(QZ)1129001 | Throttle control valve | 1 | ||
| (21) | WD10G220E23 | Engine | 1 | ||
| (21) | WD10G220E21 | Engine (for WG180) | 1 | ||
| (22) | GB5783 M12×35 | Bolt M12×35 | 8 | ||
| (23) | GB93-12 | Spring washer 12 | 8 | ||
| (24) | GB5782 M16×1.5×90 | Bolt M16×1.5×90 | 8 | ||
| (25) | GB95-16 | Flat washer 16 | 8 | ||
| (26) | GB889 M16×1.5 | Nut M16×1.5 | 8 | ||
| (27) | DG50B | Water-oil combination radiator | 1 | ||
| (27) | ZL60GT-1C | Water-oil combination radiator (big) | 1 | ||
| (28) | WD10G220E23-xsq | Muffler | 1 | ||
| (29) | WD10G220E23-pqg | Exhaust pipe | 1 | ||
| (30) | WD10G220E23-klq | Air filter | 1 | ||
| (31) | D2900-20000 | Clamp 200×8 | 3 | ||
| (32) | GB73 M14×1.5×12 | Screw M14×1.5×12 | 4 | ||
| (33) | JB3618.1 75～80 | Clamp 70～75 | 1 | ||
| (34) | JB3618.1 60～65 | Clamp 60～65 | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956WⅡ-01001 | Water tank pad | 2 | ||
| 2 | DG956A-01002 | Engine inlet hose ⅠΦ64-150 | 1 | ||
| 3 | DG956A-01003 | Water release switch | 1 | ||
| 4 | DG956A-01004 | Suction water steel pipe | 1 | ||
| 5 | DG956A-01005 | Suction water steel pipe Ⅱφ64-200 | 1 | ||
| 6 | ZL50G2-01006 | Pipe joint | 1 | ||
| 7 | DG956WI-01006 | Manometry hose | 1 | ||
| 8 | ZL50G2-01007 | Joint bolt | 1 | ||
| 9 | DG956A-01009 | Throttle flexible shaft | 1 | ||
| 10 | DG957-01200 | Fuel tank assembly | 1 | ||
| 11 | ZL50G2-01010 | Connect fork | 1 | ||
| 12 | DG956A-01012 | Throttle bracket | 1 | ||
| 13 | DG956A-01013 | Offgas injection hose | 1 | ||
| 14 | DG956A-01014 | Engine outlet pipe Ⅰφ51-250 | 1 | ||
| 15 | DG956A-01015 | Engine outlet steel pipe | 1 | ||
| 16 | DG956A-01016 | Engine outlet pipe Ⅱφ51-250 | 1 | ||
| 17 | DG956A-01017 | Engine damp pad | 2 | ||
| 18 | DG956A-01018 | Offgas injection steel pipe assembly | 1 | ||
| 20 | DG956WII-01021 | Connection tube (for CB0234) | 1 | ||
| (1) | SC11CB220G2B1-dkg | Big clamp | 4 | ||
| (2) | GB5782 M14×55 | Bolt M14×55 | 4 | ||
| (3) | GB95-14 | Flat washer 14 | 4 | ||
| (4) | GB889 M14 | Nut M14 | 4 | ||
| (5) | GB3452 10A-A-2000 | Oil transfer hose 10A-A-2000 | 1 | ||
| (6) | SC11CB220G2B1-tdq | Copper washer 14 | 2 | ||
| (7) | GB6170 M6 | Nut M6 | 1 | ||
| (8) | D00-241-01+B | Oil transfer hose | 1 | ||
| (9) | JB982 14 | Combined washer 14 | 4 | ||
| (10) | D2900-20000 | Clip 200×8 | 3 | ||
| (11) | GB882 B6×20 | Pin B6×20 | 1 | ||
| (12) | GB91 2×20 | Splint pin 2×20 | 1 | ||
| (13) | GB95 6 | washer 6 | 1 | ||
| (14) | GB5781 M6×16 | Bolt M6×16 | 5 | ||
| (15) | GB93 6 | Spring washer 6 | 5 | ||
| (16) | XZ(QZ)1129001 | Accelerator control valve | 1 | ||
| (17) | SC11CB220G2B1 | Engine (CB0235) |
|
1 |
1260000-1470000 руб. |
| (17) | SC11CB220G2B1 | Engine (CB0234) |
|
1 |
1260000-1470000 руб. |
| (18) | SC11CB220G2B1-xkg | Small clamp | 4 | ||
| (19) | SC11CB220G2B1-gkg | Pipe clamp | 2 | ||
| (20) | ZL60GT-1C | Radiator | 1 | ||
| (21) | SC11CB220G2B1-klq | Air filter | 1 | ||
| (22) | SC11CB220G2B1-xsq | Muffler | 1 | ||
| (23) | GB5782 M24×160 | Bolt M24×160 | 2 | ||
| (24) | GB93 24 | Washer 14 | 2 | ||
| (25) | GB6170 M24 | Nut M24 | 4 | ||
| (26) | GB5783 M8×25 | Bolt M8×25 | 2 | ||
| (27) | GB93-8 | Spring washer 8 | 2 | ||
| (28) | JB3618.1 75～80 | Clamp 75～80 | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956WI-01006 | Manometry hose | 1 | ||
| 2 | DG956WⅡ-01001 | Water tank pad | 2 | ||
| 3 | DG956WⅣ-01003A | Engine inlet pipe | 1 | ||
| 4 | DG956WⅣ-01004 | Engine shock pad | 2 | ||
| 5 | DG956WⅣ-01005 | Engine front bracket | 2 | ||
| 6 | DG956WⅣ-01006 | Pipe joint | 1 | ||
| 7 | DG956WⅣ-01007 | Joint bolt | 2 | ||
| 8 | DG957-01200 | Fuel tank assembly | 1 | ||
| 9 | DG956WⅣ-01009A | Throttle flexible shaft | 1 | ||
| 10 | ZL50G2-01010 | Connect fork | 2 | ||
| 11 | DG956WⅣ-01011 | Throttle bracket | 1 | ||
| 12 | DG956WⅣ-01013A | Engine outlet pipe | 1 | ||
| 13 | DG956WⅣ-01014 | Connect pipe | 1 | ||
| 14 | DG956WⅣ-01015C | Joint | 1 | ||
| 15 | DG956WⅣ-01017A | Joint | 1 | ||
| 16 | DG956WⅣ-01018 | Joint bolt | 1 | ||
| 17 | DG956WⅣ-01019 | Outlet oil pipe | 1 | ||
| (1) | JB3618.1 75～80 | Clamp 75～80 | 1 | ||
| (2) | GB5782 M14x50 | Bolt M14x50 | 8 | ||
| (3) | GB95-14 | Washer 14 | 8 | ||
| (4) | GB889 M14 | Nut M14 | 8 | ||
| (5) | D2900-20000 | Clamp 200×8 | 3 | ||
| (6) | JB982 14 | Combined washer 14 | 2 | ||
| (7) | GB3452 12B-B-1750 | Oil inlet pipe 12B-B-1750 | 1 | ||
| (8) | GB3452 8B-B-3000 | Oil outlet pipe 8B-B-3000 | 1 | ||
| (9) | GB93-22 | Spring washer 22 | 2 | ||
| (10) | GB5783 M22×60 | Bolt M22×60 | 2 | ||
| (11) | GB95-22 | Washer 22 | 2 | ||
| (12) | GB882 6×20 | Pin 6×20 | 2 | ||
| (13) | GB91 2×20 | Pin 2×20 | 2 | ||
| (14) | GB95 6 | Washer 6 | 2 | ||
| (15) | GB5781 M6x16 | Bolt M6x16 | 5 | ||
| (16) | GB93 6 | Spring washer 6 | 5 | ||
| (17) | XZ(QZ)1129001 | Throttle control valve | 1 | ||
| (18) | JB3618.1 70～75 | Clamp 70～75 | 2 | ||
| (19) | JB3618.1 60～65 | Clamp 60～65 | 1 | ||
| (20) | GB5782 M12x1.75 | Bolt M12x1.75 | 8 | ||
| (21) | GB93-12 | Washer 12 | 8 | ||
| (22) | JC1084 ZG1/8″ | Plug screw ZG1/8″ | 1 | ||
| (27) | ZL60GT-AC | Radiator | 1 | ||
| (28) | 6CTA8.3-C215 | Engine | 1 | ||
| (29) | 6CTA8.3-C215-klq | Air filter | 1 | ||
| (30) | 6CTA8.3-C215-pqg | Exhaust pipe | 1 | ||
| (31) | 6CTA8.3-C215-xsq | Muffler | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 0 | DG957-01200 | Fuel tank assembly | 1 | ||
| 1 | DG957-01201 | Fuel oil tank | 1 | ||
| 2 | ZL50G2-06206B | Rubber pad | 2 | ||
| 3 | ZL50G2-06204D | Flange | 1 | ||
| 4 | ZL50G2-01207 | Baffle | 1 | ||
| 5 | DG953-01205 | Ring flange | 1 | ||
| (1) | GB5781 M8×16 | Bolt M8×16 | 4 | ||
| (2) | GB93-8 | Spring washer 8 | 16 | ||
| (3) | QL-10-00 | Oil filling filter | 1 | ||
| (4) | GB5783 M8×20 | Bolt M8×20 | 12 | ||
| (5) | GB5783 M20×40 | Bolt M20×40 | 4 | ||
| (6) | GB93-20 | Spring washer 20 | 4 | ||
| (7) | GB95-20 | Flat washer 20 | 4 | ||
| (8) | YWZ-127 | Level indicator | 2 | ||
| (9) | GB5787 M8×25 | Bolt M8×25 | 2 | ||
| (10) | JB982 27 | Combined washer 27 | 1 | ||
| (11) | JB1000 M27×2 | Plug screw M27×2 | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | ZL50FIII(A)-09100A | Front frame (for mechanical control) | 1 | ||
| 1 | ZL50G2(A)-09100A | Front frame (for pilot control) | 1 | ||
| 2 | ZL50G2-09001A | Cover board | 1 | ||
| 4 | ZL50G2-09300D | R/pin assembly, tipping cylinder | 1 | ||
| 5 | ZL50G2-09400D | R/pin assembly, movable arm | 2 | ||
| 6 | ZL50G2-09500D | R/pin assembly, lifting cylinder | 2 | ||
| 7 | ZL50G2-09600 | F/pin assembly, steering cylinder | 2 | ||
| 9 | ZL50G2-09003 | Link bolt | 4 | ||
| 10 | ZL50G2-09700A | Lubricating pipe (2 symmetrical) | 1 | ||
| 11 | ZL50FIII(A)-09004 | Adjusting gasket | 1 | ||
| 12 | ZL50FIII(A)-09005 | Upper link shaft | 1 | ||
| 13 | ZL50FIII(A)-09006 | Washer | 6 | ||
| 14 | ZL50FIII(A)-09007 | Bearing cover | 1 | ||
| 16 | ZL50FIII(A)-09009 | Bearing base | 1 | ||
| 17 | ZL50FIII(A)-09010 | Sleeve | 1 | ||
| 18 | ZL50FIII(A)-09011 | Press board | 1 | ||
| 19 | ZL50G2-09007A | Pan | 1 | ||
| 20 | ZL50G2-09008 | Slotted nut |
|
1 |
1100-1300 руб. |
| 21 | ZL50G2-09900 | Lower jointed shaft assembly |
|
1 |
5000-6000 руб. |
| 22 | ZL50G2-09009 | Lower jointed bearing cover |
|
2 |
1900-2300 руб. |
| 23 | ZL50G2-09010 | Pad | 1 | ||
| 24 | ZL50FIII(A)-09016 | Washer | 4 | ||
| 25 | ZL50FIII(A)-09017 | Adjusting gasket | 6 | ||
| 26 | DG953-11005 | Washer | 5 | ||
| 27 | DG930A-09005 | Base | 1 | ||
| 28 | DG930A-09006 | Link bolt | 1 | ||
| (2) | GB93-12 | Spring washer 12 | 26 | ||
| (3) | GB5787 M8×20 | Bolt M8×20 | 6 | ||
| (5) | GB1152 M10×1 | Oil cup M10×1 | 10 | ||
| (6) | GB5783 M16×30 | Bolt M16×30 | 5 | ||
| (9) | GB5783 M12×30 | Bolt M12×30 | 26 | ||
| (10) | GB95-12 | Washer 12 | 2 | ||
| (11) | JB982 10 | Combined washer 10 | 13 | ||
| (12) | GB9877.1 B80×100×10 | Seal ring B80×100×10 | 1 | ||
| (13) | GB5782 M12×110 | Bolt M12×110 | 6 | ||
| (14) | GB9877.1 B85×110×12 | Seal ring B85×110×12 | 1 | ||
| (15) | GB93 48 | Spring washer 48 | 1 | ||
| (16) | GB91 6.3×90 | Cotter pin 6.3×90 | 1 | ||
| (17) | GB95-16 | Washer 16 | 1 | ||
| (18) | SJM03-1 70 | Dust ring 70 | 2 | ||
| (19) | GB5783 M16×40 | Bolt M16×40 | 5 | ||
| (20) | GB93-16 | Spring washer 16 | 1 | ||
| (21) | GB297 7514E | Bearing 7514E | 2 | ||
| (22) | GB304.5 GE70ES | Joint bearing GE70ES | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956-A17001 | Outlet Pipe | 1 | ||
| 2 | DG956-A17002 | Inlet Pipe | 1 | ||
| 3 | DG956-A17003 | Inlet Pipe | 1 | ||
| 4 | DG956-A17004 | Outlet Pipe | 1 | ||
| 0 | D2061-51000 | Air conditioner assembly | 1 | ||
| (1) | JB3618.1 16～25 | Clamp 16～25 | 8 | ||
| (2) | TSGX05010X | Air Condition Wire | 1 | ||
| (3) | GB95 10 | Washer 10 | 9 | ||
| (4) | GB93-10 | Washer 10 | 9 | ||
| (5) | GB6170 M10 | Nut M10 | 9 | ||
| (6) | GB5781 M10×45 | Bolt M10×45 | 5 | ||
| (7) | GB6170 M14 | Nut M14 | 3 | ||
| (8) | GB95-14 | Washer 14 | 2 | ||
| (9) | GB93-14 | Washer 14 | 1 | ||
| (10) | GB5781 M12×50 | Bolt M12×50 | 4 | ||
| (11) | GB93-12 | Washer 12 | 4 | ||
| (12) | GB95-12 | Washer 12 | 4 | ||
| (13) | DY5H14 | Compressor | 1 | ||
| (14) | TSZW05.DG07 | Evaporator | 1 | ||
| (15) | TSL05-DG09 | Condenser asy | 1 | ||
| (16) | GB819 M4×12 | Screw HM4×12 | 4 | ||
| (17) | GB5781 M8×30 | Bolt M8×30 | 1 | ||
| (18) | GB93-8 | Washer 8 | 4 | ||
| (19) | GB95 8 | Washer 8 | 4 | ||
| (20) | GB6170 M8 | Nut M8 | 4 | ||
| (21) | JB3618.1 65～70 | Clamp 65～70 | 4 | ||
| (22) | TSZN05.DG01-02000000 | Release switch | 1 | ||
| (23) | TSGX05023D | Hose | 1 | ||
| (24) | TSGX05023G1 | Hose | 1 | ||
| (25) | TSGX05007G2 | Hose | 1 | ||
| (26) | TSPZ.SYm | Compressor frame | 1 | ||
| (27) | TSPZ.SYm-0001 | Bolt | 1 | ||
| (28) | V13×1560 | Belt | 1 | ||
| (29) | DG938-KTTJMB | Air condition adjust panel | 1 | ||
| (30) | DG938-FD1 | Duct | 2 | ||
| (31) | DG938-ZLF | Only flow valve | 1 | ||
| (32) | GB5781-86 M10×35 | Bolt M10×35 | 4 | ||
| (33) | DYZN05.DG01-0300000 | Transition joints | 1 | ||
| (34) | DYZN05.DG01-0000002 | Outlet joint | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956A-A17001 | Outlet pipe | 1 | ||
| 2 | DG956A-A17002 | Inlet pipe | 1 | ||
| 3 | DG956A-A17003 | Inlet pipe | 1 | ||
| 4 | DG956A-A17004 | Outlet pipe | 1 | ||
| 0 | D2061-52000 | Air conditioner assembly | 1 | ||
| (1) | JB3618.1 16～25 | Clamp 16～25 | 8 | ||
| (2) | TSGX05010X | Air condition wire | 1 | ||
| (3) | GB5781 M10×45 | Bolt M10×45 | 1 | ||
| (4) | GB93-10 | Washer 10 | 1 | ||
| (5) | GB95 10 | Washer 10 | 1 | ||
| (6) | GB6170 M10 | Nut M10 | 1 | ||
| (7) | GB6170 M14 | Nut M14 | 3 | ||
| (8) | GB95-14 | Washer 14 | 2 | ||
| (9) | GB93-14 | Washer 14 | 1 | ||
| (10) | GB5781 M10×130 | Bolt M10×130 | 1 | ||
| (11) | GB5781 M10×100 | Bolt M10×100 | 1 | ||
| (12) | GB5781 M10×80 | Bolt M10×80 | 1 | ||
| (13) | GB5781 M10×65 | Bolt M10×65 | 1 | ||
| (14) | V13×1305 | Belt | 1 | ||
| (15) | DY5H14 | Compressor | 1 | ||
| (16) | TSZW05.DG07 | Evaporator | 1 | ||
| (17) | TSL05-DG09 | Condenser asy | 1 | ||
| (18) | DG938-KTTJMB | Air condition adjust panel | 1 | ||
| (19) | GB819 M4×12 | H-screw HM4×12 | 4 | ||
| (20) | GB5781 M8×25 | Bolt M8×25 | 4 | ||
| (21) | GB93-8 | Washer 8 | 4 | ||
| (22) | GB95 8 | Washer 8 | 4 | ||
| (23) | GB6170 M8 | Nut M8 | 4 | ||
| (24) | TSPZ.SYm-0001 | Bolt | 1 | ||
| (25) | DG938-FD1 | Duct | 2 | ||
| (26) | JB3618.1 65～70 | Clamp 65～70 | 4 | ||
| (30) | DG938-ZLF | Only flow valve | 1 | ||
| (31) | TSZN05.DG01-02000000 | Release switch | 1 | ||
| (32) | TSGX05008D | Hose | 1 | ||
| (33) | TSGX05008G1 | Hose | 1 | ||
| (34) | TSGX05007G2 | Hose | 1 | ||
| (35) | TSPZ.SYb-0000 | Compressor frame | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956WIV-A17001 | Outlet pipe | 1 | ||
| 2 | DG956WIV-A17002 | Inlet pipe | 1 | ||
| 3 | DG956WIV-A17003 | Engine inlet pipe | 1 | ||
| 4 | DG956WIV-A17004 | Engine return pipe | 1 | ||
| 0 | D2061-53000 | Air conditioner assembly | 1 | ||
| (1) | JB3618.1 16～25 | Clamp 16～25 | 8 | ||
| (2) | TSGX05010X | Air conditioner wiring harness | 1 | ||
| (3) | GB95 10 | Washer 10 | 15 | ||
| (4) | GB93-10 | Spring washer 10 | 15 | ||
| (5) | GB6170 M10 | Nut M10 | 12 | ||
| (6) | GB5781 M10×45 | Bolt M10×45 | 11 | ||
| (7) | GB5781 M10×35 | Bolt M10×35 | 3 | ||
| (8) | DY5H14 | Compressor | 1 | ||
| (9) | TSZW05.DG07 | Evaporator | 1 | ||
| (10) | TSL05-DG09 | Condenser assembly | 1 | ||
| (11) | GB819 M4×12 | Screw HM4×12 | 4 | ||
| (12) | GB5781 M8×25 | Bolt M8×25 | 1 | ||
| (13) | GB93-8 | Spring washer 8 | 4 | ||
| (14) | GB95 8 | Washer 8 | 4 | ||
| (15) | GB6170 M8 | Nut M8 | 4 | ||
| (16) | GB3618.1 65～70 | Clamp 65～70 | 4 | ||
| (17) | TSZN05.DG01-02000000 | Release switch | 1 | ||
| (18) | TSGX05007D | Hose | 1 | ||
| (19) | TSGX05007G1 | Hose | 1 | ||
| (20) | TSGX05007G2 | Hose | 1 | ||
| (21) | TSPZ.SYh-0000 | Compressor frame | 1 | ||
| (22) | V13×1115 | Belt | 1 | ||
| (23) | DG938-KTTJMB | Air conditioner adjusted panel | 1 | ||
| (24) | DG938-ZLF | Check-valve | 1 | ||
| (25) | DG938-FD1 | Duct | 2 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956-01301 | Inlet pipe 1 | 1 | ||
| 2 | DG956-01302 | Inlet pipe 2 | 1 | ||
| 3 | DG956-01303 | Return pipe | 1 | ||
| (1) | DG956-FSFM | Tail water valve | 1 | ||
| (2) | DG956-JSFM | Inlet water valve Z3/8″ | 1 | ||
| (3) | DG956-HSFM | Backwater valve NPT3/8″ | 1 | ||
| (4) | JB3618.1 22～26 | Clamp 22～26 | 8 | ||
| (5) | JB3618.1 65～70 | Clamp 65～70 | 2 | ||
| (6) | D2071-00000 | Heater unit | 1 | ||
| (7) | DG938-FD | Air duct | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956A-01301 | Inlet pipe 1 | 1 | ||
| 2 | DG956A-01302 | Inlet pipe 2 | 1 | ||
| 3 | DG956A-01303 | Return pipe | 1 | ||
| (1) | DG956-FSFM | Tail water valve | 1 | ||
| (2) | DG956-JSFM | Inlet water valve Z3/8″ | 1 | ||
| (3) | DG956-HSFM | Backwater valve NPT3/8″ | 1 | ||
| (4) | JB3618.1 22～26 | Clamp 22～26 | 8 | ||
| (5) | JB3618.1 65～70 | Clamp 65～70 | 2 | ||
| (6) | D2071-00000 | Heater unit | 1 | ||
| (7) | DG938-FD | Air duct | 1 |
| # | Артикул | Название | Внешний вид | Комплект | Заказать |
|---|---|---|---|---|---|
| 1 | DG956WIV-01301 | Inlet pipe 1 | 1 | ||
| 2 | DG956WIV-01302 | Inlet pipe 2 | 1 | ||
| 3 | DG956WIV-01303 | Return pipe | 1 | ||
| (1) | DG956-FSFM | Tail water valve | 1 | ||
| (2) | DG956-JSFM | Inlet water valve Z3/8″ | 1 | ||
| (3) | DG956-HSFM | Backwater valve NPT3/8″ | 1 | ||
| (4) | JB3618.1 22～26 | Clamp 22～26 | 8 | ||
| (5) | JB3618.1 65～70 | Clamp 65～70 | 2 | ||
| (6) | D2071-00000 | Heater unit | 1 | ||
| (7) | DG938-FD | Air duct | 1 |
