нажмите на изображение, чтобы посмотреть в увеличенном виде
| # | Артикул | Название | Комплект | Заказать |
|---|---|---|---|---|
| - | 2603-1360 | FRAME ASS'Y | - | |
| 1 | 2603-1349 | FRAME | 1 | |
| 1 | 2603-1349A | FRAME,MAIN | 1 | |
| 1 | 2603-1349B | FRAME | 1 | |
| 1 | 2603-1349C | FRAME,MAIN | 1 | |
| 2 | S0571061 | BOLT,HEX | 35 | |
| 3 | S5103101 | WASHER,SPRING | 35 | |
| 4 | 2624-1061 | WEIGHT;COUNTER | 1 | |
| 4 | 2624-1061A | WEIGHT;COUNTER | 1 | |
| 4 | 2624-1061B | WEIGHT;COUNTER | 1 | |
| 5 | 2120-1479A | BOLT | 4 | |
| 6 | 2114-1370 | WASHER | 4 | |
| 7 | 2403-1002 | PLATE,COVER | 1 | |
| 8 | 2180-1017A | SEAL | 1 | |
| 9 | S0511853 | BOLT,HEX | 2 | |
| 10 | S5102603 | WASHER,SPRING | 2 | |
| 11 | S0515053 | BOLT,HEX | 3 | |
| 12 | S5102703 | WASHER,SPRING | 3 | |
| 13 | 2195-2786A | BRACKET | 1 | |
| 14 | 2160-9010 | COVER | 1 | |
| 15 | 2160-9011 | CAP | 2 | |
| 16 | 2123-1715 | PIN,DOWEL | 2 | |
| 17 | 2123-1799 | LOCK | 1 | |
| 18 | 2160-1201D4 | BUSHING,RUBBER | 4 | |
| 19 | 2160-1201D6 | BUSHING,RUBBER | 1 | |
| 21 | 2160-1004D3 | BUSHING,RUBBER | 2 |
